Automatic Solder Paste Dispensing Machine
Negotiable
/ Set
1 Set(Min. Order)
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | LEADY | |
| Model Number | SOLDER320 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Application:
Suitable for SMT complex multipoint welding,spot welding and drag soldering and repair welding.save labor
Plug-in electronic components, wire and all kinds of electronic products
Feature :
-Five axis soldering machine working platform
-Tin out controller.
-Heating controller
-Soldering iron components
-Temperature control system
Specification:
Outline size:510*440*780mm (L*W*H)
Working Range: 320*275*55mm(X*Y*Z)
Drive mode:five axis simple driver
Repeated accuracy:±0.02mm
R axis accuracy:±0.05°
Slider:HIWIN
Control sys:PLC + 7’ TP
Memory size :256groups,400steps/group
Solder wire feeding:feeding by program
Temp control:Heating controller
Temp Power:150W / 320W
COM : USB
Voltage:220VAC,50HZ
Air Pressure:0.3Mpa
Weight:30kg
