Automatic Paint/food Can Making Machine/welding Equipment

FOB Price

US$ 50,000 - 60,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Sichuan, China	Brand Name	CHANGTAI
Model Number	FH18-65ZD	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

1.High quality
2.Easy to operate and maintain
3.Applicable can dia:65~180mm
4.High capability
5.Food can making equipment

Automatic paint/food can making machine/welding equipment

1.Main technical data

Mode	FH18-65ZD
Linear rate of welding	6-26m/min
Production capability	40~100Cans/min
Applicable can diameter	Φ65~Φ180mm
Applicable can height	60~280mm
Applicable material	Tinplate steel-based
Applicable material thickness	0.2~0.35mm
Seam welding landing	0.4mm 0.6mm
Seam point distance	0.5-0.8mm
Applicable copper wire diameter	Φ 1.38mm Φ 1.5mm
Cooling water	Temperature:15-20°C Pressure:0.4~05Mpa Discharge:7L/min
Compressed air consumption	600 L/min
Pressure of compressed air	0.5Mpa-0.7Mpa
Power	380V±5% 50HZ
Total power	40KVA
Dimension	1750×1100×1800mm
Weight	1800Kg

2.Latest picture

***************************************************************************

3.Our major component suppliers

1, PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.

2, Low voltage apparatus are produced by SCHNEIDER.

3, IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.

4,OMRON is our sensor supplier.

5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.

4.Can making technology process

Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling

5.Applicable types of products

aerosol cans, food cans, beverage cans, chemical cans , paint pot and square bucket etc.

Automatic paint/food can making machine/welding equipment
