Medicine Grinder/30B Series Universal Grinder
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | ZHENGAN | |
| Model Number | 30B | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
30B Series Universal Grinder
APPLICATION
The machine (set) is widely used for the fragile materials in pharmaceutical, chemical, foodstuff, and pesticide industries.
WORKING PRICIPLE
This machine utilizes the high-speed relative motion between movable and fixed fluted disc to crush the raw material to be crushed and creates friction force. The crushed raw material can be discharged through grinding chamber. Moreover, different size of raw material can be got through exchanging screen with different mesh. This machine is in conformity with the requirement s of GMP and it is made of stainless steel. No dust emissions during production process.
TECHNICALPARAMETERS
Item | Unit | 20B/20B Set | 30B/30B Set | 40B/40B Set | 60B/60B Set |
Productive Capacity | kg/h | 60-150 | 100-300 | 160-800 | 500-1500 |
Speed of Main Shaft | r/min | 4500 | 3800 | 3400 | 2800 |
Granule Size | mm | 6 | 10 | 12 | 15 |
Fineness of Pulverization | mesh | 60-150 | 60-120 | 60-120 | 60-120 |
Motor Power | kw | 4 | 5.5 | 11 | 15 |
Fan Power | kw | 1.5 | 1.5 | 1.5 | 2.2 |
Weight | kg | 250 | 320 | 550 | 680 |
Overall Dimension(L×W×H) | mm | 550×600×1250 | 600×700×1450 | 800×900×1550 | 1000×900×1680 |
Overall Dimension (set)(L×W×H) | mm | 1100×600×1650 | 1200×650×1650 | 1350×700×1700 | 1550×1000×1750 |
