MWM marine diesel generator set 200KW

Specifications

200KW  Main marine diesel generator set

Model                       CCFJ200Y-W
Rated output              200kW
Rated voltage             3 phase 400V
Rated current             360A
Rated frequency           50Hz
Power factor                0.8lag

Engine main parameters

Brand                           MWM
Model                          TBD234V8
Type                            4-storke
No. of cylinder               8
Bore                            128mm
Stroke                          140mm

Rated output                  249kW
Rated speed                 1500 r/min
Starting measure            DC 24V electric starter
Speed control               electric governor
Direction of rotation        anticlockwisesee from flywheel
cooling type                    by sea-water
Fuel oil consumption(g/kWh)  ≤196g / kWh
Manufactory                    MWM Engine Co.,Ltd.

Technical Data of Main Alternator

  Brand                          SIEMENS
  Model                          1FC2-284-4
  Rated output                205kw
  Rated voltage               3P 400V
  Rated speed                1500r/min
  Excitation type             Brushless self-excting
  Insulation System           class H
  Protection Class             IP23
  Manufactory                  Wuxi fenxi electrical machine Co., Ltd.,

Certificated by CCS , BV, ABS , DNV , GL ,RMRS etc.
