72w led panel light

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 0 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type

led panel light

Certification

CE ROHS EMC LVD

Product Description

Features

☆ Area light source: Softer and more uniform light than conventional grille lights, anti-glare

☆ Compact heat dissipation structure, less weight, higher reliability

☆ Elegant appearance, coated white or aluminum brushed on the surface available, matching well with plaster tablet, aluminum gusset, integrated suspended ceiling and other decorating materials.

☆ Hanging, buckles and recessed installation available, easy for installation and maintenance.

☆ High protection level against flying insect and dust, better than conventional grille light

☆ Ultra-slim structure, meet special engineering requirements

Applications

Factory, Super Market, Restaurant, School, Parking Pot, Tunnel, Bus Station, Subway Corridor, Garage, Warehouse

Parameters

Basic Info	Description	Panel Light-H	Panel Light-H
Basic Info	Model	CD-PL0312-40C/N/WG0A1	CD-PL0612-72C/N/WG0A3
Aspect	Material	Aluminum+PMMA	Aluminum+PMMA
	Body Color	Sliver White	Sliver White
	Dimension	W295L1195H9.5	W595L1195H9.5
Electrical	Watts(W)	40	72
	Input Voltage(V)	AC 100～240V	AC 100～240V
	Frequency	50～60Hz	50～60Hz
	Power Mode	External	External
	Power Factor	＞0.9	＞0.9
	Power Efficiency	＞87%	＞86%
Optical	LED Brand	Jingke/Hongli	Jingke/Hongli
	LED Type	2835	2835
	LED Qty.(pcs)	180	360
	Luminous Flux(lm)	2800	5040
	CCT(K)	2700～6500	2700～6500
	Light Color	Cold,Natural,Warm	Cold,Natural,Warm
	CRI(Ra)	＞80	＞80
	Beam Angle(°)	112°	112°
	Dimmable	Unavailable	Unavailable
Applications	Install Mode	Suspended、Ceiling Mounted	Suspended、Ceiling Mounted
	Operation Temperature(℃)	-10℃～40℃	-10℃～40℃
	Operation Hummidity(RH)	10%RH-90%RH	10%RH-90%RH
	Storage Temperatures(℃)	-40°～80°	-40°～80°
	Lifetime(hrs)	＞35000	＞35000
	Ingress Proctection	IP20	IP20
Protection	Energy Saving	50%	30%
	Constrasted to	2*36W Fluorescent Grille	3*36W Fluorescent Grille
	Unit Net Weight(Kg)	2.9	6.0
Packing	Qty./Carton(pcs)	15	2
	Carton Size(mm)	1280310280	134080660
	20FT Qty（）	196	348
