8W LED T5 Tube _O
- Dalian
- T/T Credit Card PayPal
You May Like
Product Details
| Type | LED Decorative Light | Certification | CE RoHS |
Product Description
Factory, Super Market, Restaurant, School, Hospital, Office
- Lamp bracket: Integrated high strength heat dissipation structure
- Longest cascading up to 25 meters
- Power Supply: Independent isolated housing, double insulation, higher reliability, PF>0.9
- Full size design for the length of whole lamp
- Fireproof plug with transparent material, cascading with no shadow
T5 Tube | |||||||||||
Model | Watts(W) | LED | Input Voltage(V) | Luminous Flux(lm) | Color Temperature(K) | CRI | PF(AC 220V) | Dimension(mm) | Weight (kg) | Material | Lifespan(h) |
CD-T503I-4C/N/WG1 | 4 | SMD 3014 | AC 176-240 | >320 | 2700-6500 | >80 | >0.95 | 22.2*33.1*300 | 0.08 | Aluminum+PC | >35000 |
CD-T506I-8C/N/WG1 | 8 | SMD 3014 | AC 176-240 | >640 | 2700-6500 | >80 | >0.95 | 22.2*33.1*600 | 0.13 | Aluminum+PC | >35000 |
CD-T509I-12C/N/WG1 | 12 | SMD 3014 | AC 176-240 | >960 | 2700-6500 | >80 | >0.95 | 22.2*33.1*900 | 0.19 | Aluminum+PC | >35000 |
CD-T512I-15C/N/WG1 | 15 | SMD 3014 | AC 176-240 | >1200 | 2700-6500 | >80 | >0.95 | 22.2*33.1*1200 | 0.23 | Aluminum+PC | >35000 |
Remark: All the above tested data deviation:±10% | |||||||||||
| Basic Info | Items | T5 Tube | T5 Tube | T5 Tube | T5 Tube |
| Model | CD-T503I-4C/N/WG1 | CD-T506I-8C/N/WG1 | CD-T509I-12C/N/WG1 | CD-T512I-15C/N/WG1 | |
| Aspect | Material | Aluminum+PC | Aluminum+PC | Aluminum+PC | Aluminum+PC |
| Body Color | White | White | White | White | |
| Dimension | W22.2*H33.1*L300 | W22.2*H33.1*L600 | W22.2*H33.1*L900 | W22.2*H33.1*L1200 | |
| Electrical | Watts(W) | 4 | 8 | 12 | 15 |
| Input Voltage(V) | AC 176~240 | AC 176~240 | AC 176~240 | AC 176~240 | |
| Frequency | 50~60Hz | 50~60Hz | 50~60Hz | 50~60Hz | |
| Power Mode | Internal | Internal | Internal | Internal | |
| Power Factor | >0.95 | >0.95 | >0.95 | >0.95 | |
| Power Efficiency | >90% | >90% | >90% | >90% | |
| Optical | LED Brand | Jingke/Hongli | Jingke/Hongli | Jingke/Hongli | Jingke/Hongli |
| LED Type | 3014 | 3014 | 3014 | 3014 | |
| LED Qty.(pcs) | 45 | 75 | 128 | 150 | |
| Luminous Flux(lm) | 320 | 640 | 960 | 1200 | |
| CCT(K) | 2700~6500 | 2700~6500 | 2700~6500 | 2700~6500 | |
| Light Color | Cold,Natural,Warm | Cold,Natural,Warm | Cold,Natural,Warm | Cold,Natural,Warm | |
| CRI(Ra) | >80 | >80 | >80 | >80 | |
| Beam Angle(°) | 120° | 120° | 120° | 120° | |
| Dimmable | Unavailable | Unavailable | Unavailable | Unavailable | |
| Application | Mounting Size(mm) | / | / | / | / |
| Socket | / | / | / | / | |
| Install Mode | Suspended,Ceiling Mounted | Suspended,Ceiling Mounted | Suspended,Ceiling Mounted | Suspended,Ceiling Mounted | |
| Operation Temperature(℃) | -10℃~40℃ | -10℃~40℃ | -10℃~40℃ | -10℃~40℃ | |
| Operation Hummidity(RH) | 10%RH-90%RH | 10%RH-90%RH | 10%RH-90%RH | 10%RH-90%RH | |
| Storage Temperatures(℃) | -40°~80° | -40°~80° | -40°~80° | -40°~80° | |
| Lifetime(hrs) | >35000 | >35000 | >35000 | >35000 | |
| Protection | Ingress Proctection | IP20 | IP20 | IP20 | IP20 |
| Waterproof | / | / | / | / |
Power Consumption Contrasts | ||||||||
Item | Cedar Integrated LED T5 Tube | Fluorescent T5 Tube | ||||||
Power(W) | 4 | 8 | 12 | 15 | 8 | 14 | 21 | 28 |
Lifespan(h) | 35000 | 35000 | 35000 | 35000 | 8500 | 8500 | 8500 | 8500 |
Annual consumption(degree) | 35.04 | 70.08 | 105.12 | 131.40 | 70.08 | 122.64 | 183.96 | 245.28 |
Remark: The above data was calculated by lamps lit 7*24. | ||||||||
