Home > Products > LED DISPLAY > Highway LED ETC/Gantry/Cantilever _O
Highway LED ETC/Gantry/Cantilever _O
USD $1 - $500
/ Piece
100 Pieces(Min.Order)
- 300 Piece / Pieces per Month
- Dalian/Shenzhen/Ningbo/Qingdao/Lianyungang
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | China | Brand Name | CEDAR | |
| Model Number | CD-WP16/25-DM | Usage | Indoor | |
| Tube Chip Color | Full Color | Display Function | Video | |
| Pixels | Other, 16mm/25mm | Screen Dimension | Customized |
Product Description
Models & Parameters
| Parameters | ETC-WP16-128 × 32 | Cantilever-WP25-128 × 96 | Gantry-WP25-432 × 48 | |
| Pixel | Pixel Setting | DIP 346 1R1G1B | Φ5 Pipe 2R1G1B | Φ5 1R/2R1G1B |
| Pixel Pitch(mm) | 16 | 25 | 25 | |
| Pixel Density(Pixel/m2) | 16 × 8 | 8 × 8 | 8 × 8 | |
| Module | Module Resolution (W/Pixel × H/Pixel) | 256 × 128 | 200 × 200 | 200 × 200 |
| Module Size (W/mm × H/mm) | 192 × 96 | 256 × 128 | 320 × 160 | |
| Cabinet | Cabinet Resolution (W/Pixel × H/Pixel) | 128 × 32 | 64 × 48 | 48 × 48 |
| Cabinet Size(W/mm × H/mm) | 2048 × 512 | 1600 × 1200 | 1200 × 1200 | |
| Material | iron | iron | iron | |
| Cabinet Weight (kg/Pcs) | 95 | 100 | 80 | |
| Cabinet Area (m²) | 1.05 | 1.92 | 1.44 | |
| Screen Weight (kg/m²) | 90 | 52 | 55 | |
| Cabinet Flatness (mm) | ≤1 | ≤1 | ≤1 | |
| Maintenance | rear | rear | rear | |
| Optical | Brightness (cd/m²) | ≥8000 | ≥8000 | ≥8000 |
| Brightness Adjustment | 32 grades auto/manually adjustment | 32 grades auto/manually adjustment | 32 grades auto/manually adjustment | |
| Color Temperature (K) | 3000 — 10000 adjustable | 3000 — 10000 adjustable | 3000 — 10000 adjustable | |
| Horizontal FOV ( °) | 120 | 120 | 120 | |
| Vertical FOV ( °) | 45 | 45 | 45 | |
| Brightness Uniformity | ≥ 90% | ≥ 90% | ≥ 90% | |
| Electrical | Peak Power Consumption (W/m²) | 600 | 625 | 555 |
| Average Power Consumption (W/m²) | 200 | 210 | 185 | |
| Input Voltage (V) | AC 220 V ± 10%(50-60Hz) | AC 220 V ± 10%(50-60Hz) | AC 220 V ± 10%(50-60Hz) | |
| System Process | Drive Mode | constant current (static) | constant current (static) | constant current (static) |
| Frame Rate (Hz) | 60 | 60 | 60 | |
| Refresh Frequency (Hz) | ≥ 600Hz | ≥ 600Hz | ≥ 600Hz | |
| Applications | Lifespan (h) | 100000 | 100000 | 100000 |
| Ingress Protection | IP65 | IP65 | IP65 | |
| Operation Temperature (℃) | -40 ~+55 | -40 ~+55 | -40 ~+55 | |
| Storage Temperature (℃) | -40 ~+85 | -40 ~+85 | -40 ~+85 | |
| Operation Humidity(RH) | 10% ~ 90%, with no condensation | 10% ~ 90%, with no condensation | 10% ~ 90%, with no condensation | |
| Storage Humimdity (RH) | 10% ~ 90%, with no condensation | 10% ~ 90%, with no condensation | 10% ~ 90%, with no condensation | |
| Others | Protocol customized available | |||
| Support on-line signal dual direction backup | ||||
| Available for being controlled by Cedar RTM Software | ||||
| Available for different signal format, such as WIFI, GPRS, 3G etc. | ||||
| Parameters can be customized | ||||
