Home > Products > LED DISPLAY > P4 indoor smd hd led display screen
P4 indoor smd hd led display screen
Negotiable
1 (Min.Order)
- T/T Credit Card
You May Like
-
P3 indoor smd hd led display screen
-
P2.5 indoor cob led display
-
P1.875 indoor hd led display screen for TV, control center
-
P1.25 COB Indoor LED Display for control center, conference, transportation
-
P2.5 COB LED Display Screen TV Indoor Conference Room Studio
-
New Full Color Video 55 Inch LED TV with COB Tech P1.875
Product Details
| Place of Origin | Jilin, China | Brand Name | Cedar | |
| Model Number | NP4-SMD | Usage | Indoor | |
| Tube Chip Color | Full Color | Display Function | Video | |
| Pixels | Other, 4mm | Screen Dimension | Customized |
Product Description
| Parameters | NP4-SMD | |
| Pixel | Pixel Setting | SMD 2121 1R1G1B |
| Pixel Pitch(mm) | 4 | |
| Pixel Density(Pixel/m2) | 62500 | |
| Module | Module Resolution (W/Pixel × H/Pixel) | 64 × 32 |
| Module Size (W/mm × H/mm) | 256 × 128 | |
| Cabinet | Receiving Card Covering (W/Pixel × H/Pixel) | 128 × 128/256 × 128 |
| Cabinet Flatness(mm) | ≤ 1 | |
| Maintenance | front | |
| Optical Paramaeters | Dot by Dot Calibration | support |
| Brightness (cd/m²) | ≥ 1000 | |
| Brightness Adjustment | 256 grades auto/manually adjustment | |
| Color Temperature (K) | 3000 — 10000 adjustable | |
| Horizontal FOV ( °) | 120 | |
| Vertical FOV ( °) | 120 | |
| Brightness Uniformity | ≥ 95% | |
| Electrical Parameters | Peak Power Consumption (W/m²) | 500 |
| Average Power Consumption (W/m²) | 160 | |
| Input Voltage (V) | AC110~240V(50-60Hz) | |
| System Process | Drive Mode | constant current (1/16 scan) |
| Frame Rate (Hz) | 60 | |
| Refresh Frequency (Hz) | ≥ 2400Hz | |
| Grey Scale(Bit) | 14 | |
| Color Capacity(Trillion) | 4.4 | |
| Applications | Lifespan (h) | 80000 |
| Operation Temperature (℃) | -20 ~ +50 | |
| Storage Temperature (℃) | -35 ~ +85 | |
| Operation Humidity(RH) | 10% ~ 90%, with no condensation | |
| Storage Humimdity (RH) | 10% ~ 90%, with no condensation | |
| Others | Support on-site dot-by-dot calibration | |
| Support on-line signal dual direction backup | ||
| Available for being controlled by Cedar RTM Software | ||
| Available for different signal format, such as AV,S-Video,VGA,DVI,HDMI,SDI,DP | ||
| Parameters can be customized | ||
