p8 outdoor smd hd led display screen

FOB Price

Negotiable

1 (Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Parameters		WP8-SMD
Pixel	Pixel Setting	SMD 3535 1R1G1B
	Pixel Pitch(mm)	8
	Pixel Density(Pixel/m2)	15625
Module	Module Resolution (W/Pixel × H/Pixel)	32 × 16
Module	Module Size (W/mm × H/mm)	256 × 128
Cabinet	Cabinet Resolution (W/Pixel × H/Pixel)	128 × 128
	Cabinet Size(W/mm × H/mm)	1024 × 1024
	Material	iron
	Cabinet Area (m²)	1.0486
	Cabinet Flatness (mm)	≤1
	Maintenance	rear
Optical Paramaeters	Dot by Dot Calibration	support
	Brightness (cd/m²)	≥5500 (calibrated@9300K)
	Brightness Adjustment	256 grades auto/manually adjustment
	Color Temperature (K)	3000 — 10000 adjustable
	Horizontal FOV ( °)	160
	Vertical FOV ( °)	120
	Brightness Uniformity	≥ 95%
Electrical Parameters	Peak Power Consumption (W/m²)	750
	Average Power Consumption (W/m²)	250
	Input Voltage (V)	AC110~240V(50-60Hz)
System Process	Drive Mode	constant current (1/4 scan)
	Frame Rate (Hz)	60
	Refresh Frequency (Hz)	≥ 2400Hz
	Grey Scale (Bit)	14
	Color Capacity(Trillion)	4.4
Applications	Lifespan (h)	50000
	Ingress Protection	IP65
	Operation Temperature (℃)	-20 ~ +50
	Storage Temperature (℃)	-35 ~ +85
	Operation Humidity(RH)	10% ~ 90%, with no condensation
	Storage Humimdity (RH)	10% ~ 90%, with no condensation
Others	Support on-site dot-by-dot calibration
	Support on-line signal dual direction backup
	Available for being controlled by Cedar RTM Software
	Available for different signal format, such as AV,S-Video,VGA,DVI,HDMI,SDI,DP
	Parameters can be customized
