Home > Products > Outdoor Circuit Breaker > Switchgear Manufacturers GIS 110kv SF6 Gas Insulated Switchgear
Switchgear Manufacturers GIS 110kv SF6 Gas Insulated Switchgear
- Ningbo/Shanghai
- T/T
You May Like
-
ZW37S-40.5 Circuit Breaker Prices 33kv Vacuum Circuit Breaker
-
ZW37S-40.5 Outdoor High Voltage AC Permanent Magnet Vacuum Circuit Breaker
-
ZW8-12 Outdoor High Voltage Alternative Current Vacuum Circuit Breaker
-
ZW27-12 Outdoor SF6 High Voltage Alternative Current Vacuum Circuit Breaker
-
ZW37-40.5 Outdoor High Voltage Alternative Current Vacuum Circuit Breaker With CT
-
ZW43A-12/24 Outdoor High Voltage Vacuum Circuit Breaker PCCC Cert
Product Details
| Place of Origin | Zhejiang, China | Brand Name | HEAG | |
| Model Number | ZFW41-126 |
Product Description
Main Products
Huayi Electric Co., Ltd(HEAG) is one of leading manufacturers in China mainly for power distribution and transmission line, at present we mainly produce the following 7 categories:
1. Wind Energy Power Systems;
2. Outdoor Power Transmission and Distribution Systems till 252kV;
3. Indoor Metal-clad switchgear and control systems;
4. Medium voltage equipment and Accessories;
5. Intrument energy meters & Protection Relays;
6. Instrument Current Transformers & Potential Transformers;
7. Mining Electrical equipment and LV electrical Apparatus.
Product Details
>> Summary :
VZF1-126 model Gas-insulated Metal-enclosed Switchgear (hereinafter referred to as GIS) is the latest improved mini nonsegregated phase GIS jointly developed on the bases of being made full use o f Russian GIS/GCB advanced technology from Lenin All-Russian Electro Technical Institute (VEI for short) by HEAG and Longyuan Research Institute (VLI for short). This product does not only accords with standard of IEC517, idt GB/T 7674-1997: Gas-insula ted metal-enclosed switchgear for rated voltages above 72.5 kV, but also conforms to IEC 62271-203-2003: High-voltage switchgear and controlgear-Part 203: Gas-insulated metal-enclosed switchgear for rated voltages above 52 kV.
>> Technical Specification :
Related Items
VHY1-12/24 Circuit Breaker JN15-12/24 Earthing Switch FZRN21-12D Combination Apparatus
Why Choose Us

>> Certifications :
>> Package :
Company View

Contact Us
We will be always at your service!
>> FAQ :
1: What certifications do you get?
A: We have ISO, CE, KEMA, SGS, etc.
2: Are OEM&ODM available?
A: Yes, we accept OEM and ODM.
3: When to get the price?
A: We usually quote within 24 hours after getting your inquiry.
if you are very urgent to get the price, please contact us with emails or calls so that we will regard your inquiry priority.
4: Is sample available and free?
A: Sample is available, but sample should be paid in advance. The cost of sample will be refund after further order.
5. How to pay?
A: T/T and L/C are acceptable, and T/T will be more appreciated.
30% deposit before producing, 70% balance before loading by T/T.
6. What is the delivery time?
A: It depends on the order quantity and the season you place the order. Generally, one month after the receipt of the 1st payment.
7. What about the Package?
A: Standard export package (Wooden carton with inner vacuum package) for long-distant ocean shipment and tough handling is provided. and we can make special designed for you if need.
8.How to contact?
A: Send your inquiry details in the below, Click “send” now!
↓
