C5126 CE manual single column vertical lathe machine

FOB Price

US$ 30,400 - 35,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Vertical
CNC or Not	Normal	Automatic Grade	Semi-Automatic
Max. Swing Diameter	2600mm	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	C5126 single column vertical lathe
Voltage	220V 380V 400V 415V 440V 480V	Power(W)	37kW
Dimension(LWH)	3300x4000x3500mm	Weight	22 tons
Certification	CE Certificate; ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

C5126 conventional single column vertical lathe

Main Featurers

Main Usage

Suitable of the turning ferrous, nonferrous metal and some kinds of non-metal materials with hard alloy etc.
It can make rough and accurate turning of external cylindrical surface, circular conical surface, head face, grooving, severance, and so on.

Main Technical Data

Specifications	Unit	Parameter
Max. turning diameter of sidehead	mm	2300
Max. turning diameter of railhead	mm	2600
Max. working height	mm	Standard: 1500 Optional: 1800/2000
Max. weight of workpiece	T	10
Table diameter	mm	2300
Speed range of table	r/min	1.2~40
Speed-step of table		16
Max. torque of table	KN.m	32
Max. cutting resistance of railhead	KN	25
Max. cutting resistance of sidehead	KN	20
Total cutting resistance	KN	40
Travel of railhead (Horizontal)	mm	1300
Travel of railhead (Vertical)	mm	1000
Travel of sidehead (Horizontal)	mm	730
Travel of sidehead (Vertical)	mm	1180
Travel of crossbeam	mm	1100/1400
Feeding range of railhead	mm/min	0.8~86
Rapid moving speed of railhead and sidehead	mm/min	1800
Moving degrees limit of railhead		±30°
Cutting section of tool bar (W×H)	mm	30×40
Moving speed of crossbeam	mm/min	440
Power of feeding motor	KW	1.3/1.8
Power of main motor (AC)	KW	37
Overall dimensions (L×W×H)	mm	3300×4000×3500 3800×4000×3500
Weight of machine	T	22

Factory Overview

kinds of colors for your choice/can be customized
