Catalogue of CW6280e horizontal manual gap lathe machine for sale
- Dalian China
- T/T Credit Card PayPal
You May Like
Product Details
Condition | New | Type | Horizontal | |
CNC or Not | Normal | Automatic Grade | Manual | |
Max. Swing Diameter | 800mm | Place of Origin | Liaoning, China | |
Brand Name | DALIAN | Model Number | CW6280Ex750~5000 gap lathe machine | |
Voltage | 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz | Power(W) | 11/15kW | |
Dimension(L*W*H) | depends | Weight | depends | |
Certification | ISO9001:2008; GB/T19001:2008 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CW6280 gap lathe machine specification
Such horizontal gap lathe machine has following features:
l Standard spindle head: C11, spindle bore Φ100mm,
Optional spindle head: D11,spindle bore Φ130mm;
l Guide rail width:550mm
l Guide rail hardness:HRC50,Depth1.5mm
l Max load weight between 2-centers:1000kg;
With steady rest: up to 2000kg;
l Standard: Left-hand wheel is equipped;
Right-handed wheel shall be informed specially when placing order;
l Equipped with hydraulic clutch and electrical cabinet;
l Slide board boxes with vertical and horizontal rapid shift handle included;
l Special indication is required iftailstock sleeve is with a scale;
Specifications | Unit | Parameter |
Max. swing over bed | mm | 800 |
Max. swing over carriage | mm | 520 |
Center distance | mm | 750 1000 1500 2000 3000 4000 5000 6000 |
Width of gap | mm | 320 |
Swing over gap | mm | 1000 |
Width of guide way | mm | 550 |
Spindle bore diameter | mm | 105 |
spindle nose |
| C11/D11 |
Spindle speed | rpm | (18 speeds) 7.5~1000 |
Longitudinal feed | mm/r | (64) 0.1~24.3 |
Cross feed | mm/r | (64) 0.05~12.15 |
Rapid traverse speed | m/min | 3.8 |
Metric thread | mm | (39)1~240 |
Inch thread | TPI | (26) 14~1 |
Module thread | mm | (53) 0.5~120 |
Diametrical pitch thread | D.P | (24) 28~1 |
Max. travel of cross slide | mm | 493 |
Travel of top slide | mm | 200 |
Main motor power | kW | 11 |
Rapid traverse motor power | kW | 1.1 |
Coolant pump motor power | kW | 0.09 |
Wooden box/Pallet packing | mm |
|
Gross/Net weight | kg |
