QC12Y-25x6000 CE hydraulic metal plate shearing machine
- Dalian/Shanghai China
- T/T Credit Card
You May Like
-
QC12Y-20x4000 CE hydraulic metal plate shearing machine
-
QC12Y-25x2500 hydraulic metal plate shearing machine
Quality Choice
-
WC67Y Hydraulic Bending machine with CE
-
WF67Y-250x3200 CE hydraulic plate bending machine
-
WF67Y-300x3200 hydraulic metal plate bending machine
-
WF67Y-300x6000 Hydraulic Plate Bending Machine with CE
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | LFM | Model Number | QC12Y-25x6000 plate shearing machine | |
| Voltage | 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz | Rated Power | 37KW | |
| Dimension(L*W*H) | 7000x3500x2800mm | Weight | 50000KG | |
| Certification | CE Certificate; ISO9001:2008; GB/T19001:2008 | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
QC12Y-25x6000 hydraulic plate shearing machine
1.Steel welding frame, sufficient strength and rigidity.
2. Hydraulic driving system, safety and reliable operation, and fine appearance.
3.Quick and flexible gap adjusting device, high shearing precision.
4. Reliable safety protection fence.
5. Digital display device(DRO) displaying extruded-plate length and shearing times.
6.Calibrating device with lamplight for measuring and shearing.
7. CE is approved;
8. Hydraulic Pendulous Shearing Machine;
9. Kinds of colors for your choice/can be Customized according to user's demand;
10. CNC types are available, too;
Kinds of colors for your choice/can be Customized according to user's demand;
QC12Y-25x6000 hydraulic plate shearing machine | Unit | Parameter |
Plate thickness | mm | 25 |
Plate width | mm | 6000 |
Shearing angle |
| 2.5° |
Throat depth | mm | 80 |
Extruded-plate length | mm | 800 |
Stroke times | times/min | 2 |
Pole distance | mm | 3445 |
Motor power | kW | 37 |
Blade length | mm | 6245 |
Blade material |
| 6crw2si |
Axial plunger pump |
| 63MCY14-1B Flow : 63ml/r Pressure: 32mpa |
Left and right wallboard | mm | 80 |
Knife rest thickness | mm | 80 |
thinkness of work table | mm | 90 |
Dimension (L×W×H) | mm | 7000×3500×2800 |
Package Dimension(L×W×H) | mm | 7400×3900×3200 |
N.W/G.W | T | 50/54 |
1. Hydraulics: Shanghai Yeer Hydraulic Co. Ltd.
2. Main electrical parts: CHINT GROUP(Zhejiang Xi'ou Electrical Appliance Co, Ltd)
3. Press-button: CHINT GROUP(Zhejiang Xi'ou Electrical Appliance Co, Ltd )
4.Oil pump: Shanghai Jisheng Hydraulic Pump Company
5. Transformer: Wuxi Zhenghuang Machine Co., Ltd.
6.Hydro-cylinder: Ma’anshan Yuhua Hydraulic Company
7. Main Hermetic Documents: imported from Japan
