Heavy-duty CNC Horizontal Lathe with CE
- 100 Set / Sets per Month
- Dalian China
- T/T
You May Like
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | CNC | Automatic Grade | Automatic | |
| Max. Swing Diameter | 1800mm | Place of Origin | Liaoning, China | |
| Brand Name | DALIAN | Model Number | CK61125 CK61140 CK61160 CK61180 | |
| Voltage | 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz | Certification | CE; ISO9001:2008; GB/T19001:2008 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Heavy Duty CNC Lathe
Main Features:
- Machine bed has three guideways or guideways on one-piece casting,
- induction hardened and ground to guarantee high accuracy ,load capacity and long life working.
Specifications | Unit | CK61125 CKW61125 | CK61140 CKW61140 | CK61160 CKW61160 | CK61180/1 CKW61180/1 | CK61125/2 CKW61125/2 | CK61140/2 CKW61140/2 | CK61160/2 CKW61160/2 | CK61180/2 CKW61180/2 |
Swing over bed | mm(in) | 1250(50) | 1400(56) | 1600(64) | 1800(72) | 1250(50) | 1400(56) | 1600(64) | 1800(72) |
Swing over carriage | mm(in) | 900(36) | 1100(44) | 1280(51) | 1480(59) | 880(35) | 1080(43) | 1280(51) | 1480(59) |
Between distance | mm(in) | 1500-8000(60-320) | 1500-8000(60-320) | 1500-8000(60-320) | 1500-8000(60-320) | 1500-8000(60-320) | 1500-8000(60-320) | 1500-8000(60-320) | 1500-8000(60-320) |
Width of bed | mm(in) | 970(39) | 970(39) | 970(39) | 970(39) |
|
|
|
|
Support capacity between centers | Kg | 8000,10000 | 8000,10000 | 8000,10000 | 8000,10000 | 15000,18000 | 15000,18000 | 15000,18000 | 15000,18000 |
Spindle hole through | mm(in) | 130(5.2) 100(4) | 130(5.2) 100(4) | 130(5.2) 100(4) | 130(5.2) 100(4) | 100(4) | 100(4) | 100(4) | 100(4) |
Spindle nose |
| ISO A2-15 | ISO A2-15 | ISO A2-15 | ISO A2-15 | ISO A2-15 | ISO A2-15 | ISO A2-15 | ISO A2-15 |
Spindle taper | mm | Metric No. 140 | Metric No. 140 | Metric No. 140 | Metric No. 140 | 140, 1:7 | 140, 1:7 | 140, 1:7 | 140, 1:7 |
Spindle speed | rpm | 3.15~ 315 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 3.15~ 315 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 3.15~ 315 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 3.15~ 315 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 2.5~ 250 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 2.5~ 250 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 2.5~ 250 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear | 2.5~ 250 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear |
Turret made by China |
| Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 | Vert.: 4 Hor.: 8,12 |
Changing time | s | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
Size of tool holder | mm(in) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) | 32×32(1.3×1.3) /45×45(1.8×1.8) |
Repeated positioning accuracy of cutterhead |
| 2" | 2" | 2" | 2" | 2" | 2" | 2" | 2" |
Rapid traverse of X-Axis & Z-Axis | mm / min | X: 4000 Z: 6000 | X: 4000 Z: 6000 | X: 4000 Z: 6000 | X: 4000 Z: 6000 | X: 4000 Z: 6000 | X: 4000 Z: 6000 | X: 4000 Z: 6000 | X: 4000 Z: 6000 |
Diameter of tailstock sleeve | mm(in) | Ø 160 | Ø 160 | Ø 160 | 160(6.4)180(7.2)200(8) | 240(9.6),280(11) |
|
|
|
Taper of tailstock quill |
|
| Metric No. 80 | Metric No.8,(Morse No.6) | 80; 1:7 |
|
|
|
|
Rapid speed of tailstock | mm/min |
| 3000 |
|
|
|
|
|
|
Inverter to change speed of motor |
| Yasakawa of Japan | Yasakawa of Japan | Yasakawa of Japan | Yasakawa of Japan | Yasakawa of Japan | Yasakawa of Japan | Yasakawa of Japan | Yasakawa of Japan |
Electrical power |
| 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
