CK61125 Series Cnc Horizontal Lathe Machine With 6 Tons Load Capacity

FOB Price

US$ 90,717 - 278,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	1250mm	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	CK61125 cnc horizontal lathe machine
Voltage	Customer's Requirement	Power(W)	22kW
Dimension(LWH)	depends	Weight	depends
Certification	CE Certificate; ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

CK61125 cnc horizontal lathe machine

Main Features

Servo main motor 22kW,

X/Z axis servo motor,

automatic 4 gears, infinitely variable speeds within the gear,

Spindle Speed: 3.15~ 315rpm, 4-position turret,

Spindle bore: φ130mm,

Bed width:755mm,

φ1000mm manual 4-jaw chuck, manual tailstock

CE Standard and CE Certificate;

Main Technical Data

Specifications	Unit	Parameter
Swing over bed	mm	1250
Swing over carriage	mm	900
Between distance	mm	2000
Dia. Of chuck	mm	1000
Cutting length	mm	1800
Width of bed	mm	755
Center height	mm	625
Support capacity between centers	kg	6000
Spindle hole through	mm	130
Spindle nose		ISO A2-15
Spindle taper	mm	Metric No. 140
Spindle speed	rpm	3.15~ 315 Manual 21 gears/ automatic 4 gears, infinitely variable speeds within the gear
Turret made by China		4 positions, vertical type
Size of tool holder	mm	32×32
Travel of X-Axis	mm	740
Travel of Z-Axis	mm	1800
Feeding speed of X-Axis & Z-Axis	mm/min.	X: 1 ~ 2,000 Z: 1 ~ 2,000
Rapid traverse of X-Axis & Z-Axis	mm/min.	X:4000Z:6000
Travel of tailstock quill	mm	300
Taper of tailstock quill		Metric No. 80
Rapid speed of tailstock	mm/min	3000
Controller		FANUC 0i mate /FANUC 0i-T
Servo motor	Nm	30 ( for X-Axis) 38 ( for Z-Axis)
power of main servo motor	kW	AC 22
Adjusting speed device of main motor		YASAKAWA OF JAPAN, F7
Electrical power		380V/50HZ
Net dimension of the machine	mm	6,100×2,210×1,790
Packing dimension of the machine	mm	1) 6,360×2,500×2,280 2)2000x860x2000
N. W./ G. W.	kg	1) 12000/ 15500 2)650/ 800
