Advanced Ford LHD Mobile Ambulance

A

Technical specs of vehicle

QTY

Fiberglass exterior and interior roof of vehicle

Wheelbase (mm):3570

Wheel tread (mm): 1692/ 1700 (front/rear)

Minimum ground clearance (mm):165

Turning diameter(m):13.8

Overall dimensions (mm):5418(+ rear pedal: 5618)×1974×2720

Dimension of Patient's compartment (mm):3000×1700×1850

Complete vehicle curb mass:(kg):2050

GVW (kg):3300

Engine: 4G64S4N(petrol)

Fuel type:  Petrol

Fuel consumption:9L/100km

Working manner: in-line, 4 cylinders, 4 strokes, water-cooled

Displacement (ml.):2351

Emission standard:Euro IV,GB18352.3-2005 China IV

Maximum power:92kw

Gearbox:MT-75 5 speed, manual

Chassis :JX6546C-H

Front overhang:independent suspension

Rear overhang:variable cross-section steel spring, hydraulic shock absorber

Brake: Front disc rear drum, power-assisted brake

Max. speed (Km/h):130

Steering system: gear, rack power-assisted steering

Tire:225/70R15C-8PR(tubeless type)

Fuel tank capacity(L):68

B

Standard configuration of vehicle

1

Manual side mirror

2

Power window

3

Vehicle-mounted radio cassettes

4

Central control door lock

5

Hand-free Intercom system between driver's cab and Patient's compartment

6

3 seats in driver's cab

7

Double open rear door

8

Foot pedal in rear door

C

Air conditioner and lighting system

1

Vehicle-mounted air conditioner in driver's cab

1

2

Vehicle-mounted air conditioner in Patient's compartment

1

3

Ventilation fan mounted on the roof of Patient's compartment

1

4

2 illumination lights each side of vehicle outside

4

5

1 illumination light rear side of vehicle outside

1

6

illumination light front side of vehicle outside

1

7

illumination light in Patient's compartment

2

8

spotlight lights inner roof of Patient's compartment

2

9

Ultraviolet radiation disinfector light

1
