hot slae!!!depth 120-300m, diameter:168-300mm,KW30 High-Effect Hydraulic Geothermal Water Well Drilling Rigs

1)type:crawler2)diameter:168-300mm3)depth:300m

Model

KW30

Total weight(Kg)

9500

size(mm)

5200×2300×3200

Travel speed(Km/h)

0~2.5

Drive type (yuchai)

YC6B150Z-T21

Drive parameter

110Kw/2100rpm

Ground clearance(mm)

280

hammer

DHD360(DHD380)

Climb slope ability(°)

25

Drill depth(m)

300

Work wind pressure(MPa)

1.05-2.46

Air consumption(m3/min)

16-40

Drill rod(mm)

φ89-φ102

Drill rod length(mm)

3000/4000

Drill hole diameter(mm)

φ168-300

propulsion(N)

50000

Lifting Power(N)

150000

Spindle Rotary Speed(rpm)

slow

43/52/69

fast

85/102/125

Swing torque(N·m)

slow

8000

fast

4000

Model

LGCY-33/25

Air delivery (m3/min)

33

Working Pressure(Bar)

25

Total weight(kg)

6800

Overall dimension(mm)

4700×2100×2500

Tire Size X quantity

 7.50-16×4

        Diesel engine

manufacturer

Cummins

Model

QSZ13-C550

Type

Vertical array water

Inspiratory way

charge inter-cooling

Cylinder diameter X stroke X number of cylinders

130×163×6

 output volume(L)

13.0

rated speed(r/min)

1800

Unloading speed(r/min)

1300

rated power(HP)

550

Diesel engine oil capacity(L)

35

Fuel Tank Capacity(L)

600

Electrical system voltage(v)

24

       compressor

No of compression stage

2

Compressor oil capacity(L)

80

air supply valve   size X quantity

G2×1,G3/4×1
