Manufacturer for JY - SZ1600 Auotmaticl Slitter Rewinder Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port ningbo port

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Slitting Rewinder
Computerized	No	Place of Origin	Zhejiang, China
Brand Name	wzjinyue	Model Number	JY-SZ1600
Voltage	3*380 V	Power(W)	7.5 KW
Dimension(LWH)	295026001500	Weight	3000 KG
Certification	CCIS	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

manufacturer for JY - SZ1600 auotmaticl slitter rewinder machine

Product Description

USE:

Suitable for all kinds of kraft paper, tea paperboard, grass paperboard, calico and art paper cutting

FEATURE:

1. Two blades cutting; thicken blade;

2. The two side of the paper will be smooth after the cutting, without any burring;

3. Tray paper will be tidy with two sides feat;

4. With the computer rectified system and it can rectified automatically;

5. All the operation will be finished on the panel with ease operation;

6. With high capacity, the single machine can be provided for three sets of reel-pipe machine;

7. S.S structure body; beautiful performance;

8. Pneumatic discharge with easy operation

9. Double magnetic powder brake control, and with equally tension

Technical Parameter		Control system
Jumbo roll width	25-1600 mm	PLC controller	Delta DVP14SS2
Un-winder diameter	1300 mm	Touch screen	MCGS TPC7062
Re-winder diameter	800 mm	transducer	YASKAWA
Slitting speed	0-300 m/min	Electrical product	Schneider
Slitting range	20-900 g	Signal part	Omron
Re-winding method	stalk involution	Pneumatic part	AIRTAC
Blade quantity	21 pairs	Driving system
Load paper roll	Automatically motor driven	Main motor	7.5 KW
Speed adjust	Transducer	Load paper power	2.2 KW
Power supply	3*380V	Correction motor	Y110 6:1
Mainframe & Weight		Winding reducer	WPA120
Un-winder part	150023501200 mm	Load paper reducer	WPA100
Re-winder part	145026001500 mm	Driving way	Connected bearing
Up-blade	105704	Equipped devices
Low-blade	105704	Load paper way	Automatically motor driven
Weight	3000 KGS	Unload paper way	Electric hoist
Accessories		Auto edge correction	Electric screw correct device
Useful tool	1 set	Counter meters	Automatically counter
Wrench	Hex wrench	Tension correction	Pneumatic adjust
One instruction manual		Brake	Double steam brake adjustment

1.OEM service is welcome!

2.We will provide all the details to you during the mass production

3.Customize your mould according to your need

4.Your requirements and complains are highly respected

5.Necessary test and certification can be obtained as you request

6.Our technician and engineers are available to go abroad for machine commissioning and teach how to operate machines.

7.Any spare part of our machines, you can buy from us.

With 15 years OEM experience, we can provide professional solutions for customers. Send your Inquiry Details in the below, click “Send”NOW!
