ABB PFXA401SF 3BSE024388R4 Controller

ABB PFXA401SF 3BSE024388R4 is a high-performance analog input module specifically designed for industrial automation systems. It is mainly used to accurately collect, process, and convert various analog signals (such as temperature, pressure, flow, liquid level, etc.) in industrial sites, and transmit them to upper-level control systems (such as PLC, DCS), providing reliable raw data for system monitoring, control, and decision-making. With its high-precision measurement capability, strong anti-interference performance, and flexible adaptability, this module plays a key role in many industrial fields such as electric power, chemical industry, metallurgy, and water treatment. It is an important component for realizing refined control and intelligent management in industrial production processes.

•


• Number of Input Channels: Equipped with 8 independent analog input channels, it can collect multiple different types of analog signals simultaneously, meeting the needs of multi-parameter monitoring in industrial sites. For example, in the monitoring of chemical reactors, it can collect multiple parameters such as temperature, pressure, liquid level, and flow at the same time.

• Input Signal Types: Supports various common analog input signals, including 4mA-20mA DC current signals, 0V-10V DC voltage signals. Some channels are also compatible with thermocouple (such as K-type, J-type) and thermal resistance (such as Pt100) signals. It can directly connect to various sensors in industrial sites without additional signal conversion equipment, simplifying system wiring.

• Measurement Accuracy: Measurement accuracy is guaranteed for different signal types. Among them, the measurement accuracy of current and voltage signals is as high as ±0.1% of full scale, and that of thermocouple and thermal resistance signals is ±0.2% of full scale, ensuring that the collected data is accurate and reliable, providing a strong basis for precise control. In scenarios requiring high-precision temperature control, such as constant temperature control in semiconductor production workshops, it can accurately reflect subtle changes in temperature.

• Resolution: The resolution reaches 16 bits, which can finely quantify analog signals, capture small fluctuations of signals, ensure the accuracy and integrity of signal conversion, and is especially suitable for occasions with high requirements for signal precision.

• Isolation Performance: Optoelectronic isolation technology is adopted between channels with an isolation voltage of 2500V AC. Electrical isolation is also achieved between input and output, effectively preventing signal interference between channels and the impact of on-site strong electricity on the module and upper-level control systems, improving the safety and anti-interference ability of the system, and is suitable for use in complex electromagnetic environments.

• Sampling Rate: The maximum sampling rate of each channel is 100Hz, which can quickly collect dynamic changes of signals. For rapidly changing process parameters (such as instantaneous pressure impact), it can capture and feed back to the control system in real time, ensuring timely response of the system.

• Working Power Supply: The working power supply is 24V DC, with a current of about 200mA during normal operation. It has low power consumption, is compatible with standard DC power supplies in industrial sites, and reduces heat generation of the module itself, which is beneficial to extending the service life of the module.

• Environmental Adaptability: The operating temperature range is -40℃-70℃, and it can operate stably in extreme high and low temperature environments, such as outdoor equipment rooms in northern winter or high-temperature metallurgical workshops; the relative humidity is 5%-95% RH (non-condensing), which can adapt to humid coastal factories or workshop environments in rainy seasons, ensuring performance stability under complex environmental conditions.

• Physical Specifications: The module has a compact size, approximately 130mm×100mm×70mm, and weighs about 350g. It adopts DIN rail mounting, which is easy to install, occupies little space in the control cabinet, and is convenient for combined installation with other modules, optimizing the cabinet layout.

•


• Flexible Signal Configuration: Supports independent configuration of signal type, range, filtering parameters, etc. of each channel through configuration software. Users can flexibly set according to the characteristics of on-site sensors and measurement needs to meet the monitoring requirements of different scenarios. For example, for pressure signals that are susceptible to interference, high-frequency noise can be filtered out by setting filtering parameters.

• Powerful Signal Processing Capability: Built-in signal conditioning circuit can amplify, filter, linearize the collected original signals, reduce distortion and interference during signal transmission, and improve signal quality. At the same time, it has cold junction compensation function (for thermocouple signals), which automatically compensates for the impact of ambient temperature changes on measurement results, ensuring the accuracy of temperature measurement.

• Self-Diagnosis and Alarm Functions: Equipped with complete self-diagnosis functions, it can real-time monitor the module's power supply status, channel faults (such as disconnection, short circuit), etc., and send fault information to the upper-level control system through the communication interface, while triggering the fault indicator light to alarm. Operators can quickly locate the fault point according to the alarm information, shortening the fault Investigation time.

• Strong Anti-Electromagnetic Interference: Adopting multi-layer shielding and optimized circuit layout design, it can effectively resist electromagnetic radiation, radio frequency interference, etc. in industrial sites. Even in environments close to strong interference sources such as frequency converters and high-power motors, it can maintain the stability and accuracy of signal collection.

• Wide Compatibility: Compatible with mainstream DCS systems such as ABB Symphony Plus, and supports industrial communication protocols such as Modbus and Profibus. It can seamlessly connect with control systems and equipment of different brands, facilitating system integration and upgrade, and reducing users' equipment replacement costs.

•


• Chemical Process Parameter Monitoring: In the chemical production process, it is installed on equipment such as reactors and pipelines to collect key parameters such as temperature, pressure, liquid level, and flow. The DCS system conducts real-time monitoring and analysis of these parameters. When the parameters exceed the preset range, the control strategy is adjusted in time to ensure that the chemical reaction is carried out under safe and stable conditions.

• Power Equipment Status Monitoring: In the monitoring of turbine generator sets in power plants, it collects parameters such as bearing temperature, lubricating oil pressure, and steam flow, providing data support for equipment status evaluation and fault early warning. When abnormal parameters are detected, an alarm is issued in time to avoid major losses caused by equipment shutdown due to faults.

• Water Treatment Process Monitoring: In sewage treatment plants, it is used to collect parameters such as pH value, dissolved oxygen concentration, and turbidity of sewage. The control system adjusts dosing devices, aeration equipment, etc. to ensure that the sewage treatment effect meets the discharge standards. For example, according to the monitoring data of dissolved oxygen concentration, the air volume of aeration equipment is automatically adjusted to optimize treatment efficiency.

• Parameter Control of Manufacturing Production Lines: In automobile parts production lines, it collects parameters such as welding temperature, stamping pressure, and cutting fluid flow, and feeds them back to the production line control system in real time to ensure that all parameters in the production process meet the process requirements and ensure the consistency of product quality. When parameters are abnormal, the control system can stop and adjust in time to avoid the production of unqualified products.
