ABB 3HNA025019-001 Industrial Controller

ABB 3HNA025019-001 is a high-performance power supply module belonging to ABB's industrial automation control product series. It assumes the important responsibility of providing stable and reliable power for related equipment in industrial control systems. Designed specifically to meet the stringent requirements for power supplies in industrial environments, it can convert input AC power into stable DC power, supplying electricity to various industrial control equipment such as robot controllers, PLC modules, and sensors. It is one of the key components ensuring the continuous and stable operation of industrial automation systems.

With its high power conversion efficiency, excellent voltage regulation capability, and robust overload and short-circuit protection functions, this module can work stably in complex industrial electromagnetic environments and is widely used in industrial scenarios with high requirements for power quality and reliability.

•


• Input Parameters: The input voltage range is AC 100-240V, with a frequency of 50/60Hz. It can adapt to power voltage standards in different regions and industrial sites, featuring strong versatility.

• Output Parameters: The output voltage is DC 24V, the output current can reach 10A, and the rated output power is 240W, which can meet the simultaneous power supply needs of multiple small industrial control devices.

• Voltage Regulation Rate: When the input voltage fluctuates and the load changes, the regulation rate of the output voltage does not exceed ±0.5%, ensuring the stability of the output voltage and providing a stable working power supply for the equipment.

• Ripple and Noise: The ripple and noise of the output voltage are small, with a peak-to-peak value usually not exceeding 100mV, effectively reducing interference to sensitive electronic equipment and ensuring the normal operation of the equipment.

• Protection Functions: It is equipped with multiple protection functions such as overload protection, short-circuit protection, over-voltage protection, and over-temperature protection. When abnormal situations like overload or short-circuit occur, the module will automatically cut off the output to avoid damaging itself and the connected equipment, and can automatically resume output after the fault is eliminated.

• Environmental Parameters: The operating temperature range is 0-50℃, and the storage temperature range is -40-70℃; the relative humidity is 5%-95% (non-condensing); it has a certain ability to resist vibration and impact, meeting the usage requirements of industrial environments.

• Efficiency: The power conversion efficiency is high, reaching over 90% under rated load, which can effectively reduce energy loss and operating costs.

• Dimensions: Adopting a compact design, the overall dimensions are approximately 150mm×100mm×60mm (length × width × height), facilitating installation and layout in the control cabinet and saving space.

•


• Stable and Reliable Power Supply: Through high-precision voltage regulation circuits and advanced filtering technology, it ensures stable output voltage with extremely low ripple and noise, providing clean and reliable power for industrial control equipment. It reduces equipment failures caused by power fluctuations and ensures the stable operation of the system.

• Comprehensive Protection Mechanism: The integration of multiple protection functions enables it to quickly respond to abnormal situations such as overload, short-circuit, over-voltage, and over-temperature by cutting off the output, effectively protecting the safety of the module itself and downstream equipment, and improving the reliability and safety of the system.

• High Efficiency and Energy Saving: The high power conversion efficiency can reduce energy loss during power conversion, lower the operating power consumption of the equipment, conform to the development trend of energy conservation and emission reduction in the industrial field, and at the same time reduce the self-heating of the module, extending its service life.

• Wide Range Adaptability: The wide input voltage range can adapt to voltage changes of AC 100-240V, making it suitable for power standards in different countries and regions, and convenient for application in industrial scenarios worldwide; it has strong adaptability to environmental temperature, humidity, etc., and can work stably in relatively harsh industrial environments.

• Easy Installation and Maintenance: The modular design and standardized installation methods (such as DIN rail mounting) make the installation process simple and convenient, allowing for quick integration into industrial control systems; the module surface is equipped with status indicators that can intuitively display the working status of the power supply (such as normal operation, fault, etc.), facilitating maintenance personnel to quickly troubleshoot and improve maintenance efficiency.

•


•


• Industrial Robot Systems: It provides stable DC power for components such as controllers, drive modules, and sensors of industrial robots, ensuring that robots can accurately and efficiently complete various operational tasks, such as automobile welding and electronic component assembly.

• Automated Production Lines: In automated production lines for automobile manufacturing, food processing, packaging, etc., it supplies power to equipment such as PLC control modules, solenoid valves, photoelectric sensors, and human-machine interfaces, ensuring the coordinated work of various equipment in the production line and improving production efficiency and product quality.

• Power Automation: It is applied in the automation control systems of substations and power plants, providing reliable power for measurement and control devices, communication equipment, relays, etc., ensuring the normal operation of monitoring and control functions of the power system and guaranteeing the safety and stability of the power system.

• Rail Transit: In signal systems and monitoring systems of rail transit such as subways and light rails, it supplies power to related control equipment and electronic devices, ensuring the safe and efficient operation of rail transit.

• Medical Equipment: In the control systems of some industrial-grade medical equipment, it provides stable power for precision control circuits and sensors, ensuring the accurate operation and reliability of medical equipment.
