Used KONICA MINOLTA Spectrophotometer CM - 2600d

Product Details

The KONICA MINOLTA CM - 2600d is a high - performance portable spectrophotometer that has been widely used in various industries for accurate color measurement. This used CM - 2600d unit is still in good working condition and offers excellent value for those in need of a reliable color measurement solution.

1. Ergonomic and User - friendly Design

The CM - 2600d features an ergonomic design, allowing for easy one - hand operation. It is equipped with a unique "navigation wheel", similar to a computer mouse, which enables convenient menu navigation. There is also a dedicated measurement button, making the operation simple and intuitive.

The large LCD display clearly shows measurement data in both graphical and numerical forms. It can display information such as pass/fail indicators, chromaticity values with color difference descriptions, and Lab* color graphs with box - shaped or elliptical tolerances. The display can be rotated, ensuring clear visibility even when the device is transferred between hands.

2. High - Precision Color Measurement

Optical System: It adopts a d/8° (diffuse illumination, 8° directional reception) optical system with an integrated sphere. The entire optical system includes high - energy xenon arc illumination and a high - resolution integrated double - beam monochromator, without any moving parts, ensuring high durability and reliability.

Measurement Range: The measurement wavelength range is from 360nm to 740nm, with a measurement wavelength interval of 10nm and a half - width of approximately 10nm. The reflectance measurement range is from 0 to 175%, with a display resolution of 0.01%.

Repeatability and Error: It offers excellent repeatability. The standard deviation of spectral reflectance is within 0.1% (within 0.2% in the wavelength range of 360 - 380nm), and the standard deviation of color values is within ΔEab0.04 after white calibration (when the white calibration plate is measured 30 times at 10 - second intervals). The instrument error is within ΔEab0.2 (MAV/SCI) based on the average value measured by the host for the BCRA Series II 12 - color samples.

3. Dual Aperture for Versatile Measurements

The CM - 2600d can switch between two measurement apertures: ?8mm (MAV) and ?3mm (SAV). This feature allows for flexible and accurate measurement of samples of various sizes and shapes. Whether measuring large - area samples or small and detailed parts, this spectrophotometer can provide precise results, eliminating the need for time - consuming averaging measurements on structured surfaces and avoiding incorrect results when measuring small - sized samples.

4. SCI/SCE and UV Control

SCI/SCE Measurement: It can simultaneously measure SCI (including the specular component) and SCE (excluding the specular component) in just 1.5 seconds. The digital gloss control, which has no mechanical moving parts, alternately lights two xenon arc lamps (for SCI and SCE), providing excellent optical performance and long - term durability for portable applications.

UV Control: As the world's first portable instrument with patented digital UV control, the CM - 2600d significantly shortens the calibration and measurement time when measuring products treated with brighteners, such as textiles, paper, and detergents. Instead of using traditional methods like mechanically driven filters, it uses two xenon arc lamps (one with UV and one without UV) and a special algorithm for UV control.

5. Multilingual and Software - Compatible

Multilingual Interface: The built - in software supports six languages: English, German, French, Spanish, Italian, and Japanese, facilitating international color communication and cooperation.

Software Compatibility: It is compatible with software such as SpectraMagic NX, which can record measurement results and provide more comprehensive color analysis for color quality control.

6. Wide Application Fields

This used CM - 2600d is suitable for a wide range of industries, including plastics, coatings, electronics, chemical products, cosmetics, printing, building materials, and textiles. It can be used for quality control in production processes, research and development of new products, and color matching to ensure color consistency and meet strict color standards.
