Introduction to Schneider Electric 140CRA93100 Module

The 140CRA93100 is an Ethernet communication processor module in Schneider Electric's Modicon Quantum series, designed to enable high-speed data interaction between PLCs and Ethernet devices. Supporting multiple industrial protocols, this module provides reliable network connections, making it suitable for distributed control systems and remote I/O applications.

Core Functional FeaturesMulti-Protocol Support

• Compatible with Modbus TCP and Ethernet/IP protocols, operating as both master and slave stations to enable seamless integration with third-party devices.

• Supports RSTP (Rapid Spanning Tree Protocol) for network redundancy, ensuring fast switching (<50ms) in case of communication link failures.

High-Speed Data Processing

• Equipped with 10/100Mbps adaptive Ethernet interfaces, providing 2 RJ45 ports (1 service port + 1 interconnect port) and supporting daisy-chain topology.

• Configurable for up to 31 remote I/O stations, enabling efficient management of distributed I/O systems.

Real-Time Monitoring and Diagnostics

• Displays module status (power, operation, communication, error) intuitively via LED indicators.

• Supports Syslog protocol and port mirroring for easy network fault troubleshooting and remote maintenance.

Industrial-Grade Reliability

• Operating temperature: 0°C ~ 60°C; storage temperature: -40°C ~ 85°C; humidity: 95% (non-condensing).

• Resistant to vibration (10-55Hz) and shock (15g), complying with industrial environment standards.

Technical Parameters

Application ScenariosManufacturing Automation

• Connects robots, CNC machines, AGVs, etc., to enable shop-floor data collection and collaborative control.

• Typical case: Distributed I/O system in automotive production lines, synchronizing welding and assembly data in real time via Ethernet.

Energy and Infrastructure

• Remotely monitors substations, pump stations, wind turbines, etc., supporting SCADA system integration.

• Example: Natural gas pipeline pressure monitoring system communicating with RTUs via Modbus TCP.

Smart Factory and IIoT

• Serves as an edge node to transmit field data to cloud platforms (e.g., Schneider EcoStruxure), supporting predictive maintenance and data analysis.

• Adapts to industrial IoT architectures and is compatible with protocols like MQTT (requires gateway devices).

Water Treatment and Environmental Protection

• Connects sensors, valves, and pumps in sewage treatment plants to enable remote control and water quality monitoring.

• Supports multi-protocol conversion for easy integration of legacy equipment with new systems.

Installation and Configuration

• Installation Method: Standard DIN rail mounting, directly integrable into Quantum racks.

• Configuration Tools: Parameter setting via Unity Pro or EcoStruxure Control Expert software, supporting online diagnostics and firmware upgrades.

• Network Topology: Supports star, bus, and ring structures; redundant configurations are recommended for enhanced reliability.

Alternative Models and Compatibility

• Replaces early-model 140CRA31200, offering higher communication bandwidth and protocol compatibility.

• Fully compatible with other Quantum series modules (e.g., CPU, I/O modules) and supports hot-swappable maintenance.



•
