- Henan TMR Aluminum Industry Co.,Ltd.
-
Luoyang, Henan, China
- Main products: Aluminum Sheet, Aluminium Coil, Aluminium Slug, Aluminium Foil
Home > Products > Aluminium Diamond Plate > 6061 T6 Aluminum Diamond Tread Plate for Marine Decking/Railway Vehicles/Aviation Walkways - Salt Spray & Corrosion Resistant (EN 485 Certified)
6061 T6 Aluminum Diamond Tread Plate for Marine Decking/Railway Vehicles/Aviation Walkways - Salt Spray & Corrosion Resistant (EN 485 Certified)
Negotiable
/ Metric Ton
1 Metric Ton(Min. Order)
- Qingdao/Shanghai
- T/T L/C
- 30 days
You May Like
-
1200 Aluminum Diamond Plate for Wind Tower Internals & Marine Decking– Truck Bed, Loading Ramps, Cold Storage Floors (Non-Slip, T6, 0.4-8mm)
-
1100 Marine-Grade Aluminum Diamond Plate for Wind Tower Walkways & Truck Bed Liners - Non-Slip Industrial Flooring (T6 Temper, 0.4-8mm)
-
1050 High-Conductivity Aluminum Diamond Plate for EV Battery Enclosures & Data Center Flooring – Non-Slip Dock Ramps (H14 Temper, 1-6mm)
-
3003 Decorative Aluminum Diamond Plate for Luxury Interior Wall Cladding & Architectural Ceilings – Anti-Fingerprint Brushed Finish (H14, 1-4mm)
-
1070 H14 Stucco Embossed Aluminum Coil Sheet for Refrigeration/Pipe Insulation/Lighting Fixtures (High Thermal Conductivity)
-
1060 Anti-Slip Diamond Plate - Lightweight, Corrosion-Resistant & Recyclable Aluminum Sheet
Product Details
| Certification | ISO9001 | Grade | 6000 Series | |
| Color | Other, As required | Technique | Other, Rolling, embossing | |
| Application | Other, ship / vessel, railway, aviation | Surface Treatment | Other, Hard Anodizing, Nano-Ceramic Coating, Chromate-Free Conversion, Electropolishing | |
| Alloy | Alloy | Temper | T3 - T8 | |
| Transport Package | Wooden pallet | Specification | Width: 10-2300mm; Thickness: 0.4-8mm | |
| Trademark | TMR | Origin | China |
Product Description
6061 T6 Aluminum Diamond Tread Plate
(Marine/Railway/Aviation Grade | ISO Certified | Corrosion Resistant)
Product Highlights
? Ultra-Durable – Salt spray resistance 5,000+ hours (ASTM B117-2025)
? Lightweight Strength – 60% lighter than steel, 275MPa yield strength
? Industry-Specific Solutions – Customized for ship decks, train floors & aircraft MRO
? Global Certifications – EN 485, DNV GL, FAA AC 25.607-1B compliant
Technical Specifications
| Parameter | Specification | Test Standard | ||
|---|---|---|---|---|
| Alloy | AA6061-T6 (Al-Mg-Si-Cu) | ASTM B209 | ||
| Thickness | 3-12mm (*5/6/8mm Ready Stock*) | ISO 7591 | ||
| Diamond Pattern | Raised 1.0-1.3mm, R11 anti-slip | DIN 51130 | ||
| Surface Treatment | Hard Anodized (25-50μm) / Chromate-Free | MIL-A-8625F | ||
| Tensile Strength | 310-340 MPa | EN 10002-1 | ||
| Thermal Conductivity | 167 W/m·K | ASTM E1461 | ||
| Weight | 5mm: 13.5kg/m2 | 6mm: 16.2kg/m2 | 8mm: 21.6kg/m2 |
Alloy Composition
| Element | Content (%) | Functional Benefit |
|---|---|---|
| Aluminum | ≥95.8 | Base material |
| Magnesium | 0.8-1.2 | Enhances strength & weldability |
| Silicon | 0.4-0.8 | Improves heat treatment response |
| Copper | 0.15-0.40 | Increases machinability |
High-Demand Applications① Marine & Offshore
Ship Decks – 6mm hard-anodized, withstands ISO 20340 C5-M corrosion
Oil Rig Walkways – Non-sparking surface for Zone 1 hazardous areas
② Railway Innovations
High-Speed Train Floors – 5mm with EN 45545-2 HL3 fire rating
Subway Access Panels – EMI shielding (≤10?Ω surface resistance)
③ Aerospace MRO
Aircraft Maintenance Platforms – 8mm, FAA-approved for up to 800kg/m2 loads
Helideck Repair Kits – Pre-cut with non-reflective matte finish
Performance Comparison
| Property | 6061-T6 | 5052-H32 | Advantage |
|---|---|---|---|
| Corrosion Life | 25+ years (marine) | 15 years | 67% longer |
| Weld Efficiency | 98% porosity-free | 89% | 10% better |
| Cost per kg | $3.45 (2025 avg) | $2.90 | Premium justified |
Certifications & Compliance
Marine: DNV GL-RU-SHIP Pt.2 Ch.3 (2025)
Rail: EN 15085 CL1 + BS EN 13977:2025
Aviation: NADCAP AMS 4027 Rev.H
Ordering Flexibility for SMEs
MOQ: 1MT (mix thickness allowed)
Lead Time: 15 days for ready stock (30 days for custom sizes)
