MKER Planetary Gear Reducer
- Shanghai
- T/T PayPal Other
You May Like
Product Details
| Type | Planetary Gear Reducer | Application | Motor, Electric Cars, Machinery, Marine, Agricultural Machinery, Car, Other | |
| Installation | Vertical Type | Layout | Coaxial | |
| Step | Other | Gear Shape | Other, Straight teeth,Helical teeth | |
| Hardness | Hardened Tooth Surface | Origin | China |
Product Description
MKER Series
The MVER 40 from HBN is a high-efficiency mechanical component engineered for precision and durability in demanding industrial applications. Below are its key specifications:
Performance Parameters
Maximum Torque (T?): 68-80 Nm
Rated Output Torque (T?): 34-40 Nm
Efficiency: 90% (or 90 Nm, if typographical)
Emergency Braking Torque: To be specified
Maximum Input Speed: 6000 min?1
Rated Input Speed: 3300 min?1
Maximum Tilting Moment: Nm (data to be specified)
Maximum Axial Force: 2700 N
Maximum Radial Force: 3000 N
Moment of Inertia: 0.25-0.38 kg·cm2
Weight: 4.1 kg
Lubrication: Lifetime Lubrication (operating range: -15°C to 45°C)
Maximum Operating Temperature: To be specified
Protection Rating: IP65 (dust-tight and protected against water jets)
Operating Noise: ≤60 dB(A)
Paint Color: Gray
Features
High torque capacity with efficient power transmission (90% efficiency).
Designed for high-speed operations (up to 6000 min?1).
Robust construction to withstand significant axial and radial forces.
Maintenance-free with lifetime lubrication.
IP65-rated for resistance to dust and water, ensuring reliability in harsh environments.
Low-noise operation for improved workplace conditions.
