MKF Series Planetary Reducer Gearbox
- Shanghai
- T/T PayPal Other
You May Like
-
MAE Series MAE 60 Planetary Reducer Gearbox
-
MAB Series MAB 90 Planetary Reducer Gearbox
-
MVB Series MVB 060 Planetary Reducer Gearbox
-
Intelligent Small Laser Marking Machine for Metal Products
-
Intelligent Fiber Laser Marking Machine for Metal and Non-Metal Materials
-
Handheld Smart Laser Marking Machine for Metal
Product Details
| Type | Planetary Gear Reducer | Application | Motor, Electric Cars, Machinery, Marine, Agricultural Machinery, Car, Other | |
| Installation | Vertical Type | Layout | Coaxial | |
| Step | Single-Step | Gear Shape | Other, Straight teeth,Helical teeth | |
| Hardness | Hardened Tooth Surface | Origin | China |
Product Description
MKF Series
Technical Specifications:
Torque Performance:
? Maximum Torque (T?a): 2800-3500Nm
? Rated Output Torque (T?n): 1600-2500Nm
? Extreme Braking Capacity: 8750Nm Emergency Torque
? Maximum Roll Torque: 5900Nm
Speed & Power Transmission:
? Input Speed Range: 2000-3500 rpm
? High Efficiency: 90% (η)
? Moment of Inertia: 21.2-27.5 kg·cm2
Load Capacity:
? Massive Axial Force: 33,000N
? Radial Force: Data not specified
Robust Construction:
? Heavy-Duty Weight: 65.5 kg
? IP65 Protection Standard
? Lifetime Lubrication System
? Wide Operating Temperature: -15°C to +45°C
? Moderate Noise Level: ≤77 dB(A)
? Industrial Gray Finish
Engineering Advantages:
? Designed for extreme torque applications
? Heavy-load capacity for industrial use
? Maintenance-free operation
? Reliable performance in demanding conditions
Industrial Applications:
Heavy machinery drives
Mining equipment
Steel rolling mills
Large-scale material handling
Marine propulsion systems
