Miniature Reducer
≥1 Units
- T/T
You May Like
Product Details
| Type | Gear Reducer | Application | Motor, Motorcycle, Machinery, Marine, Agricultural Machinery | |
| Step | Four-Step |
Product Description
Strong bearing capacity, with a high-strength die-cast aluminum alloy case and gears with carbon hardness HRC62.
Low noise, exquisite design, precision manufacturing, noise below 65dB(A)
High efficiency, compared to traditional cone gears and worm gear reducers, it has a higher transmission efficiency at the same speed ratio.
No maintenance, the whole machine is compact, the reducer is lubricated with grease, maintenance-free for life
Wide application, a variety of models and installation methods are widely used in most industries
High torque, multiple speeds, wide power range
| OUTPUT HORSEPOWER | 50HZ | 60HZ | |||||||||||
| 110V | 220V | RPM | 110V | 220V | RPM | ||||||||
| 100w | 2.4 | 1.2 | 1400 | 2.3 | 1.2 | 1690 | |||||||
| 200W | 3.6 | 1.8 | 1400 | 3.5 | 1.7 | 1690 | |||||||
| 400W | 8 | 4 | 1410 | 7.8 | 3.9 | 1700 | |||||||
| 750W | 14 | 7 | 1410 | 13.6 | 6.8 | 1700 | |||||||
| 1500W | 24 | 12 | 1420 | 23.3 | 11.6 | 1710 | |||||||
| OUTPUT HORSEPOWER | Single Capacitor Type | Dual-capacitor type | |||||||||||
| Start cap | Operating capacitor | ||||||||||||
| 75W | 8μF | ||||||||||||
| 100w | 12μF-16μF | - | |||||||||||
| 200W | 14μF-20μF | ||||||||||||
| 400w | - | 200μF | 20μF | ||||||||||
| 750W | - | 300μF | 40μF | ||||||||||
| 1500w | - | 400μF | 40μF | ||||||||||
| OUTPUT HORSEPOWER | 50HZ | 60HZ | ||||||||||||||||||||||
| 220V | 380V | 415V | 440V | RPM | 220V | 380V | 440V | 460V | RPM | |||||||||||||||
| 100W | 0.73 | 0.42 | 0.38 | 0.36 | 1320 | 0.71 | 0.41 | 0.35 | 0.34 | 1584 | ||||||||||||||
| 200W | 1.13 | 0.65 | 0.60 | 0.56 | 1348 | 1.10 | 0.63 | 0.54 | 0.52 | 1617.6 | ||||||||||||||
| 400W | 1.99 | 1.15 | 1.05 | 0.99 | 1355 | 1.93 | 1.12 | 0.96 | 0.92 | 1626 | ||||||||||||||
| 750W | 3.45 | 1.99 | 1.82 | 1.72 | 1385 | 3.35 | 1.93 | 1.67 | 1.59 | 1662 | ||||||||||||||
| 1500W | 6.3 | 3.64 | 3.33 | 3.14 | 1420 | 6.11 | 3.53 | 3.05 | 2.92 | 1704 | ||||||||||||||
| 2200W | 8.73 | 5.04 | 4.61 | 4.35 | 1425 | 8.47 | 4.89 | 4.22 | 4.04 | 1710 | ||||||||||||||
| 3700W | 13.91 | 8.03 | 7.35 | 6.94 | 1430 | 13.49 | 7.79 | 6.73 | 6.43 | 1716 | ||||||||||||||
| 5500W | 19.89 | 11.48 | 10.51 | 9.91 | 1440 | 19.29 | 11.14 | 9.62 | 9.20 | 1728 | ||||||||||||||
| 7500W | 26.52 | 15.31 | 14.02 | 13.22 | 1450 | 25.72 | 14.85 | 12.83 | 12.27 | 1740 | ||||||||||||||
