IKO Nanoline Precision Positioning Workbench NT...XZ for Semiconductors and Clean Environments

Product Introduction: The IKO direct drive calibration worktable SA.......... DE uses IKO self-lubricating linear guide rails L for its linear guide part, and IKO cross roller bearings for its rotating guide part. The drive part adopts a direct drive method, making it a low profile compact calibration worktable for XY θ motion.

High precision positioning: The calibration workbench SA and DE achieve high-precision positioning without backlash by combining a high resolution linear grating ruler with full closed-loop control.

Three axis free combination: In addition, the X-axis movable worktable for linear movement and the rotating positioning part θ axis turntable have been standardized, making it easy to combine the X-axis and θ axes or calibrate the XY axis worktable.

There are two types of decomposition energies: 0.1 μ m and 0.5 μ m for the X and Y axes driven by linear motors, which can be selected according to their applications.

Company Profile: Shenzhen Nenel Transmission Technology Co., Ltd. was established in 2012, committed to exploring the market for linear transmission products and expanding the professionalism of the transmission product field. We provide professional technical support and services in the electronic semiconductor industry (solar energy, flat panel displays, hard drives, LEDs, printed circuit boards, optics), medical device industry, automation equipment and other industries. Enterprise products include industrial robots, precision modules, and linear transmission product components, aimed at improving the efficiency and accuracy of production lines. The main cooperative brands are: IKO from Japan, IGW from Japan, KSS from Japan, and issoku from Japan.

0755 8179 8578

For more information, please feel free to call us for consultation.
