Product Description
1.Product overview
Turbine flow meter is the velocity type flow meter, designed based on the principle of moment balance, used for the measurement of liquid flow in a pipe. lt has the advantages of simple structure.light weight, high accuracy, good reproducibility, convenient installation and maintenance, which is widely used in petroleum, chemical, metallurgy, water, paper and other industries.
2.Main technical parameters
Nominal diameter(mm):DN10~DN500
Nominal pressure(MPa):1,1.6,2.5,4,16,25,32,35,45
Accuracy level:1.0,1.5
Output signal: 4~20mA current output, pulse output
Communication interface:RS-485,RS-232
Power supply: Micro power batteries
Range ratio: 10:1
Flow range: see the table below
| Nominal diameter (mm ) | 10 | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 |
| Minimum flow (m3/h) | 0.15 | 0.6 | 0.8 | 1 | 1.5 | 2 | 4 | 7 | 10 | 20 | 25 | 30 | 80 |
| Maximum flow (m3/h) | 1.5 | 6 | 8 | 10 | 15 | 20 | 40 | 70 | 100 | 200 | 250 | 300 | 800 |
