Module spare parts　G408-0001

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

Termination Cables CABLE LENGTHS Up to 30 m (98 ft) CABLE MATERIALS Polyurethane or Low Smoke Zero Halogen (LSZH) TERMINATION CABLE TYPE Type 4 - Refer to Table 2 CABLE CONNECTION 37-pin male D-subminiature Construction - Termination Assembly MATERIAL Polypropylene (PVC), compression PVC, ring lug FAMILY GROUP COLOR Raspberry red - analog TERMINAL BLOCKS Inputs - 2 tiers, 14 positions Field Termination Connections COMPRESSION - ACCEPTED WIRING SIZES Solid/Stranded/AWG 0.2 to 4 mm2/0.2 to 2.5 mm2/24 to 12 AWG Stranded with Ferrules 0.2 to 2.5 mm2 with or without plastic collar RING-LUG - ACCEPTED WIRING SIZES #6 size connectors (0.375 in (9.5 mm)) 0.5 to 4 mm2/22 AWG to 12 AWG TERMINATION ASSEMBLIES AND CABLES Field I/O signals connect to the FBM subsystem via DIN rail mounted termination assemblies, which are electrically passive. TAs for the FBM212 module are available in the following forms: ? Compression screw type using Polyvinyl Chloride (PVC) material ? Ring lug type using Polyvinyl Chloride (PVC) material. Each FBM212 Termination Assembly and its associated termination cable provide feedthrough connection between fourteen 2-wire thermocouple/mV analog input signals and the FBM212 Differential Thermocouple/mV Input Module. The thermocouples cannot be grounded. For grounded thermocouple applications, the FBM202 and its associated termination assembly must be used. Reference junction temperature compensation is provided by an isolated resistance temperature detector (RTD) that is integral to the termination assembly. See “FUNCTIONAL SPECIFICATIONS - TERMINATION ASSEMBLIES” on page 7 for a list of TAs used with the FBM212 module. A removable termination cable connects the DIN rail mounted TA to the FBM via a field connector on the baseplate in which the FBM is installed. Termination cables are available in the following materials: ? Polyurethane ? Low Smoke Zero Halogen (LSZH). Termination cables are available in a variety of lengths, up to 30 meters (98 feet), allowing the termination assembly to be mounted in either the enclosure or in an adjacent enclosure. See Table 2 for a list of termination cables used with the TAs for the FBM212 module.
