Module spare parts　FI820F 3BDH000031R1

Focus on DCS, PLC, robot control system and large servo system.

Main products: various modules / cards, controllers, touch screens, servo drivers.

Advantages: supply of imported original products, professional production parts,

Fast delivery, accurate delivery time,

The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

BIN Binary Input BINR Binary Input Redundant BOUT Binary Output IIN Integer Input IOUT Integer Output PAKIN Packed Input PAKOUT Packed Output PLSOUT Pulse Output RIN Real Input RINR Real Input Redundant ROUT Real Output STRIN String Input STROUT String Output The DCI blocks are configured just like other Foxboro DCS control blocks. The DCI blocks address and read/write data from/to the addressed field device. Standard, Rugged Design The FBM233 has a rugged extruded aluminum exterior for physical and electrical protection of the circuits. Enclosures, specially designed for mounting the FBMs, provide various levels of environmental protection, up to Class G3 harsh environments per ISA Standard S71.04. High Reliability The redundancy of the module pair, coupled with the high coverage of faults, provides very high subsystem availability time. Either module may be replaced without upsetting field input or output signals to the other module. A module can be removed or replaced without removing power to the other FBM modules in the Modular Baseplate. 6 PSS 41H-2S233 Features FBM233 Field Device System Integrator Module, 10/100 Mbps Ethernet, Redundant Modular Baseplate Mounting The module mounts on a Modular Baseplate, which accommodates up to four or eight FBMs. The Modular Baseplate is either DIN rail mounted or rack mounted. The Modular Baseplate includes signal connectors for the FBMs, provides connections for independent DC power supplies, I/O cable connections, 2 Mbps Module Fieldbus connections. Redundant modules must be located in odd and adjacent even positions on the baseplate (positions 1 and 2, 3 and 4, 5 and 6, or 7 and 8). Visual Indicators Light-emitting diodes (LEDs) incorporated into the front of the module provide visual indication of the module’s operational status, and the communication activity (Transmit or Receive) of the Ethernet ports. Two additional LEDs provide the master or tracker status of the modules. PSS 41H-2S233 7 FBM233 Field Device System Integrator Module, 10/100 Mbps Ethernet, Redundant Functional Specifications Functional Specifications Communications Bus Characteristics ? Communication Type Ethernet ? Communication Transmission Rate 10 or 100 Mbps ? Communication Protocol UDP/IP or TCP/IP ? IP Address Fixed or DHCP NOTE: For driver specific limitations on I/O Capacity and Data Types Transferred, refer to the corresponding driver PSS or User’s Guide. I/O Capacity ? Up to 64 devices per FBM233 maximum (number of actual devices is performance dependent) with up to 2000 DCI connections. Data Types Transferred ? 2-byte or 4-byte signed or unsigned integers, 4-byte IEEE single-precision floating values, or binary values. Automatic conversion for other types as implemented in the downloadable driver. Fastest Allowed ECB Block Period ? 500 msec Module Fieldbus Communication Communicates with its associated F
