Product Description

precision equal section thin ball bearing KA035XPO KA035XP0 88.9X101.6X6.35

A deep groove bearing with reduced shoulder on one side of inner or outer race ball path. Snapover assembly permits use of a one-piece circular pocket ring separator and greater ball complement. These bearings will accept radial load and single direction thrust load and are normally used in conjunction with another bearing of similar construction. Type A bearings require the application of thrust to establish contact angle.

Type	precision equal section thin section ball bearing
inside Diameter (mm):	88.9
Outside Diameter (mm):	101.6
Width (mm):	6.35
Rows Of Balls:	single row
Seal:	open
Ring Material:	Chrome Steel /GCr15SiMn
Rolling Element Material:	Chrome Steel/GCr15SiMn
Cage Material:	Plastic, steel ,brass
Magnetic:	yes
Product weight:	0.082

Related Products

pls check the bearing as following:

BEARING	DIMENSION					BALLS	Weight	exchange number
	d mm	D mm	B mm		Kg	KAYDON	SILVERTHIN
PXAA10	25.4	34.925	4.763	21	0.014	KAA10XL0	SAA10XL0
PXAA15	38.1	47.625	4.763	29	0.018	KAA15XL0	SAA15XL0
PXA020	50.8	63.5	6.35	27	0.045	KA020XP0	SA020XP0
PXB020	50.8	66.675	7.938	23	0.073	KB020XP0	SB020XP0
PXA025	63.5	76.2	6.35	33	0.059	KA025XP0	SA025XP0
PXB025	63.5	79.375	7.938	28	0.091	KB025XP0	SB025XP0
PXA030	76.2	88.9	6.35	39	0.068	KA030XP0	SA030XP0
PXB030	76.2	92.075	7.938	33	0.109	KB030XP0	SB030XP0
PXA035	88.9	101.6	6.35	45	0.082	KA035XP0	SA035XP0
PXB035	88.9	104.775	7.938	38	0.122	KB035XP0	SB035XP0
PXA040	101.6	114.3	6.35	51	0.086	KA040XP0	SA040XP0
PXB040	101.6	117.475	7.938	43	0.136	KB040XP0	SB040XP0
PXC040	101.6	120.65	9.525	35	0.204	KC040XP0	SC040XP0
PXD040	101.6	127	12.7	27	0.354	KD040XP0	SD040XP0
PXF040	101.6	139.7	19.05	19	0.862	KF040XP0	SF040XP0
PXG040	101.6	152.4	25.4	15	1.633	KG040XP0	SG040XP0
PXA042	107.95	120.65	6.35	54	0.091	KA042XP0	SA042XP0
PXB042	107.95	123.825	7.938	45	0.141	KB042XP0	SB042XP0
PXC042	107.95	127	9.525	37	0.213	KC042XP0	SC042XP0
PXD042	107.95	133.35	12.7	28	0.376	KD042XP0	SD042XP0
PXF042	107.95	146.05	19.05	20	0.907	KF042XP0	SF042XP0
PXG042	107.95	158.75	25.4	15	1.724	KG042XP0	SG042XP0
PXA045	114.3	127	6.35	57	0.1	KA045XP0	SA045XP0
PXB045	114.3	130.175	7.938	48	0.15	KB045XP0	SB045XP0
PXC045	114.3	133.35	9.525	39	0.218	KC045XP0	SC045XP0
PXD045	114.3	139.7	12.7	30	0.399	KD045XP0	SD045XP0
PXF045	114.3	152.4	19.05	21	0.953	KF045XP0	SF045XP0
PXG045	114.3	165.1	25.4	16	1.814	KG045XP0	SG045XP0
PXA047	120.65	133.35	6.35	60	0.104	KA047XP0	SA047XP0
PXB047	120.65	136.525	7.938	50	0.154	KB047XP0	SB047XP0
PXC047	120.65	139.7	9.525	41	0.227	KC047XP0	SC047XP0
PXD047	120.65	146.05	12.7	31	0.426	KD047XP0	SD047XP0
PXF047	120.65	158.75	19.05	22	0.998	KF047XP0	SF047XP0
PXG047	120.65	171.45	25.4	17	1.86	KG047XP0	SG047XP0
PXA050	127	139.7	6.35	63	0.109	KA050XP0	SA050XP0
PXB050	127	142.875	7.938	53	0.172	KB050XP0	SB050XP0
PXC050	127	146.05	9.525	43	0.263	KC050XP0	SC050XP0
PXD050	127	152.4	12.7	33	0.454	KD050XP0	SD050XP0
PXF050	127	165.1	19.05	23	1.043	KF050XP0	SF050XP0
PXG050	127	177.8	25.4	18	1.95	KG050XP0	SG050XP0
PXA055	139.7	152.4	6.35	69	0.113	KA055XP0	SA055XP0
PXB055	139.7	155.575	7.938	58	0.186	KB055XP0	SB055XP0
PXC055	139.7	158.75	9.525	47	0.268	KC055XP0	SC055XP0
PXD055	139.7	165.1	12.7	36	0.481	KD055XP0	SD055XP0
PXF055	139.7	177.8	19.05	25	1.134	KF055XP0	SF055XP0
PXG055	139.7	190.5	25.4	19	2.132	KG055XP0	SG055XP0
PXA060	152.4	165.1	6.35	75	0.127	KA060XP0	SA060XP0
PXB060	152.4	168.275	7.938	63	0.2	KB060XP0	SB060XP0
PXC060	152.4	171.45	9.525	51	0.286	KC060XP0	SC060XP0
PXD060	152.4	177.8	12.7	39	0.526	KD060XP0	SD060XP0
PXF060	152.4	190.5	19.05	27	1.225	KF060XP0	SF060XP0
PXG060	152.4	203.2	25.4	21	2.313	KG060XP0	SG060XP0
PXA065	165.1	177.8	6.35	81	0.136	KA065XP0	SA065XP0
PXB065	165.1	180.975	7.938	68	0.213	KB065XP0	SB065XP0
PXC065	165.1	184.15	9.525	55	0.308	KC065XP0	SC065XP0
PXD065	165.1	190.5	12.7	42	0.553	KD065XP0	SD065XP0
PXF065	165.1	203.2	19.05	29	1.315	KF065XP0	SF065XP0
PXG065	165.1	215.9	25.4	22	2.449	KG065XP0	SG065XP0
PXA070	177.8	190.5	6.35	87	0.141	KA070XP0	SA070XP0
PXB070	177.8	193.675	7.938	73	0.227	KB070XP0	SB070XP0
PXC070	177.8	196.85	9.525	59	0.331	KC070XP0	SC070XP0
PXD070	177.8	203.2	12.7	45	0.594	KD070XP0	SD070XP0
PXF070	177.8	215.9	19.05	31	1.451	KF070XP0	SF070XP0
PXG070	177.8	228.6	25.4	24	2.631	KG070XP0	SG070XP0
PXA075	190.5	203.2	6.35	93	0.154	KA075XP0	SA075XP0
PXB075	190.5	206.375	7.938	78	0.24	KB075XP0	SB075XP0
PXC075	190.5	209.55	9.525	63	0.354	KC075XP0	SC075XP0
PXD075	190.5	215.9	12.7	48	0.64	KD075XP0	SD075XP0
PXF075	190.5	228.6	19.05	33	1.542	KF075XP0	SF075XP0
PXG075	190.5	241.3	25.4	25	2.767	KG075XP0	SG075XP0
PXA080	203.2	215.9	6.35	99	0.172	KA080XP0	SA080XP0
PXB080	203.2	219.075	7.938	83	0.259	KB080XP0	SB080XP0
PXC080	203.2	222.25	9.525	67	0.381	KC080XP0	SC080XP0
PXD080	203.2	228.6	12.7	51	0.694	KD080XP0	SD080XP0
PXF080	203.2	241.3	19.05	35	1.588	KF080XP0	SF080XP0
PXG080	203.2	254	25.4	27	2.948	KG080XP0	SG080XP0
PXA090	228.6	241.3	6.35	111	0.2	KA090XP0	SA090XP0
PXB090	228.6	244.475	7.938	93	0.299	KB090XP0	SB090XP0
PXC090	228.6	247.65	9.525	75	0.426	KC090XP0	SC090XP0
PXD090	228.6	254	12.7	57	0.78	KD090XP0	SD090XP0
PXF090	228.6	266.7	19.05	39	1.769	KF090XP0	SF090XP0
PXG090	228.6	279.4	25.4	30	3.266	KG090XP0	SG090XP0
PXA100	254	266.7	6.35	123	0.227	KA100XP0	SA100XP0
PXB100	254	269.875	7.938	103	0.331	KB100XP0	SB100XP0
PXC100	254	273.05	9.525	83	0.481	KC100XP0	SC100XP0
PXD100	254	279.4	12.7	63	0.853	KD100XP0	SD100XP0
PXF100	254	292.1	19.05	43	1.95	KF100XP0	SF100XP0
PXG100	254	304.8	25.4	33	3.583	KG100XP0	SG100XP0
PXA110	279.4	292.1	6.35	135	0.236	KA110XP0	SA110XP0
PXB110	279.4	295.275	7.938	113	0.34	KB110XP0	SB110XP0
PXC110	279.4	298.45	9.525	91	0.526	KC110XP0	SC110XP0
PXD110	279.4	304.8	12.7	69	0.934	KD110XP0	SD110XP0
PXF110	279.4	317.5	19.05	47	2.177	KF110XP0	SF110XP0
PXG110	279.4	330.2	25.4	36	3.901	KG110XP0	SG110XP0
PXA120	304.8	317.5	6.35	147	0.254	KA120XP0	SA120XP0
PXB120	304.8	320.675	7.938	123	0.376	KB120XP0	SB120XP0
PXC120	304.8	323.85	9.525	99	0.567	KC120XP0	SC120XP0
PXD120	304.8	330.2	12.7	75	1.021	KD120XP0	SD120XP0
PXF120	304.8	342.9	19.05	51	2.359	KF120XP0	SF120XP0
PXG120	304.8	355.6	25.4	39	4.218	KG120XP0	SG120XP0
PXB140	355.6	371.475	7.938	143	0.476	KB140XP0	SB140XP0
PXC140	355.6	374.65	9.525	115	0.689	KC140XP0	SC140XP0
PXD140	355.6	381	12.7	87	1.238	KD140XP0	SD140XP0
PXF140	355.6	393.7	19.05	59	2.722	KF140XP0	SF140XP0
PXG140	355.6	406.4	25.4	45	4.899	KG140XP0	SG140XP0
PXB160	406.4	422.275	7.938	163	0.544	KB160XP0	SB160XP0
PXC160	406.4	425.45	9.525	131	0.785	KC160XP0	SC160XP0
PXD160	406.4	431.8	12.7	99	1.406	KD160XP0	SD160XP0
PXF160	406.4	444.5	19.05	67	3.221	KF160XP0	SF160XP0
PXG160	406.4	457.2	25.4	51	5.579	KG160XP0	SG160XP0
PXB180	457.2	473.075	7.938	183	0.612	KB180XP0	SB180XP0
PXC180	457.2	476.25	9.525	147	0.88	KC180XP0	SC180XP0
PXD180	457.2	482.6	12.7	111	1.579	KD180XP0	SD180XP0
PXF180	457.2	495.3	19.05	75	3.583	KF180XP0	SF180XP0
PXG180	457.2	508	25.4	57	6.214	KG180XP0	SG180XP0
PXB200	508	523.875	7.938	203	0.68	KB200XP0	SB200XP0
PXC200	508	527.05	9.525	163	0.98	KC200XP0	SC200XP0
PXD200	508	533.4	12.7	123	1.746	KD200XP0	SD200XP0
PXF200	508	546.1	19.05	83	4.037	KF200XP0	SF200XP0
PXG200	508	558.8	25.4	63	7.167	KG200XP0	SG200XP0
PXC250	635	654.05	9.525	203	1.22	KC250XP0	SC250XP0
PXD250	635	660.4	12.7	153	2.173	KD250XP0	SD250XP0
PXF250	635	673.1	19.05	103	4.944	KF250XP0	SF250XP0
PXG250	635	685.8	25.4	78	8.845	KG250XP0	SG250XP0
PXC300	762	781.05	9.525	243	1.456	KC300XP0	SC300XP0
PXD300	762	787.4	12.7	183	2.599	KD300XP0	SD300XP0
PXF300	762	800.1	19.05	123	5.897	KF300XP0	SF300XP0
PXG300	762	812.8	25.4	93	10.569	KG300XP0	SG300XP0
PXF350	889	927.1	19.05	143	6.849	KF350XP0	SF350XP0
PXG350	889	939.8	25.4	108	12.292	KG350XP0	SG350XP0
PXF400	1016	1054.1	19.05	163	7.802	KF400XP0	SF400XP0
PXG400	1016	1066.8	25.4	123	13.971	KG400XP0	SG400XP0

Product packaging

Packing ： 1. Industrial packing 2. Single box +carton +pallets /case 3. According to customers demand Delivery time : 1. Generally after payment: within 3 days . 2. If need produce , about 30 days Payment A less USD1000 , 100% T/T in advance . 1. More USD1000 , 30% T/T in advance , 70%T/T before shipment

Shipping : by sea/by air/by express like EMS FEDEX TNT DHL...

Application

Factory

Company introduction

LANDLION BEARING CO.,LTD is an export-oriented enterprise, specializing in manufacturing and marketing several types of bearings for more than 10 years. We can produce the bearings accordingly to the customers' samples or drawings.LANDLION has a large top brand bearing NSK NTN UBC ASAHI IKO NACHI KOYO in stock.

FAQ

Q: Are you trading company or manufacturer ? A: We are factory and trader . Q: How long is your delivery time? A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: What is your terms of payment ? A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment. If you have another question, pls feel free to contact us .
