Home > Products > Road Construction Machinery > Motor Grader Original Small Motor Grader 919 Motor Grader SEM919
Motor Grader Original Small Motor Grader 919 Motor Grader SEM919
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
190HP Mini New Motor Grader for Sale SEM919
-
SEM919 China New Grader Motor 190HP Motor Grader for Sale SEM919
-
Brand New Official GR215 215HP Motor Graders Grader Cheap Price for Sale GR215 GR2153
-
High Quality New Motor Graders 190HP Motor Grader for Sale SEM919
-
Top Brand New 16 Ton Road Roller Machine Road Roller Price Hydra Roller XS163J
-
Top Brand New 16 Ton Single Drum Vibratory Roller Steel Road Roller Machine XS163J
Product Description
Contact Way
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Annie Li
Mobile / Whatsapp / Wechat: +86138 1769 0558
Products Description
Tandem Axle
* Leveraging designing and experience on MG tandem axle
* Improved bearing Layout and optimized load distribution with 4 planetary gears final drive
* Less down time and reduced labor and service cost for maintenance and repairing
* Longer service interval for lubrication oil change
* Leading in class manufacturing and quality control level, mandatory performance testing before delivering to MG assembly line
Control System
* 7 position link bar with electric over hydraulic control allows ease of operation from within the cab
* Optimum blade reach capability, quick DCM re-positioning for greater reach for better working on high bank side slope
* The link bar is essential for extending reach capability when cutting a bank slope or back slope of a ditch
* Replaceable bushings reduce service time and cost
* Leveraging designing and experience on MG tandem axle
* Improved bearing Layout and optimized load distribution with 4 planetary gears final drive
* Less down time and reduced labor and service cost for maintenance and repairing
* Longer service interval for lubrication oil change
* Leading in class manufacturing and quality control level, mandatory performance testing before delivering to MG assembly line
Control System
* 7 position link bar with electric over hydraulic control allows ease of operation from within the cab
* Optimum blade reach capability, quick DCM re-positioning for greater reach for better working on high bank side slope
* The link bar is essential for extending reach capability when cutting a bank slope or back slope of a ditch
* Replaceable bushings reduce service time and cost
Specification
Model | SEM919 |
Standard | 15,070 kg / 15.370 kg (With ROPS) |
With Front & Rear Counterweight | 15,870 kg / 16,170 kg (With ROPS) |
With Front Blade | 16,270 kg / 16,570 kg (With ROPS) |
With Ripper+Front Blade | 17,280 kg / 17,580 kg (With ROPS) |
Top Speed, Forward | 40 kph |
Top Speed, Reverse | 25 kph |
Min. Turning Radius | 7,800 mm |
Articulation Angle, Left /Right | 20 ° |
Gradeability | 30 ° |
Wheelbase | 6,140 mm |
Travel Speed, Forward | 5.3/9.1/12/20/25/40 kph |
Travel Speed, Reverse | 5.3/12/25 kph |
Drawbar Pull | 85 kN |
Model | SEM921 |
Operating Weight | 15,930 kg |
Engine Model | SC9D220G2 |
Rated Power | 162 kW/217 hp |
Overall Dimensions L*W*H | 8854x2630x3360 mm |
Blade Length | 4,279 mm |
Max. Drawbar | 85 kN |
Max. Lift above Ground (Blade) | 475 mm |
Max. Depth of Cut (Blade) | 715 mm |
Max. Blade Tip - Forward | 40º |
Max. Blade Tip - Rear | 5º |
Front Axle Steering Angle Left/Right | 47.5º |
Min. Turning Radius | 7.8 m |
Tandem Oscillation (Front up) | 15º |
Tandem Oscillation (Rear up) | 25º |
Transmission Model | 6WG180 |
Gears | F6/R3 |
Tires | 17.5-25 |
