16 ton pneumatic tyre roller price heavy duty rubber tyre roller XP163

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Products Description

XP163 pneumatic tire roller is self-propelled static roller, which is applicable to compacted asphalt pavement, foundation layer, secondary foundation layer and flling engineering and is the indispensable compaction equipment of road construction and water conservancy construction. In particular, compaction of asphalt surface course of highways can obtain compaction effect that other compaction machinery cannot reach.

Performance Characteristics:
* Pavement layer will be compacted by special pneumatic tire. It will not damage compaction materials. Flexible compacting function of tire can make compaction material obtain dense pavement surface course.

* Ground pressure of the tire can be regulated by decreasing or increasing balance weight and changing inflation pressure of tire to enhance compaction performance and enlarge the scope of application; compacted sandy soil, composite soil and clay soil can obtain good compaction effect to avoid false compaction phenomenon.

* Full hydraulic steering, air-assist hydraulic brake and multi-gear shifting transmission system are utilized, fast and flexible.
It is more convenient for transfer between construction sites.

* Front wheel swing mechanism will be adopted. When the roller is working on unleveled ground, the uniform wheel pressure grounding can be guaranteed and unleveled part of compacted materials can be compacted uniformly.

* Clutch operation mechanism adopts oil-gas boosting system so that operation is simple and labor-saving; air-pushing oil pressure amplification system makes the brake system safe and reliable.

* The equipment has water spray system as standard that can spray water to the tire surface to effectively prevent asphalt
adhesion. Optional intemittent spraying function is available..

Specification

Item			Unit	XP163
Maximum operating mass			kg	16000
Ground pressure			kPa	150~ 300
Travel speed	Gear I	km/h	4
		Gear II	km/h	8.3
		Gear II	km/h	17.5
Theoretical gradeability			%	20
Minimum turning radius			mm	7330
Minimum ground clearance			mm	260
Compaction width			mm	2250
Overlapped volume of roller			mm	45
Tires	Specification		11.00-20
Tires		Quantity		Front 4 rear 5
Engine	Type		SC4H115.4G2B
		Rated power	kw	86
		Fuel consumption	g/kw.h	≤205
Total length			mm	4800
Total width			mm	2356
Total height			mm	3330
Diesel tank volume			L	150
Water tank volume			L	650
