Cat6 Networking Brass Pvc Enclosure Cable Gland Cable Connector M Type
- T/T Credit Card
You May Like
-
Pvc Enclosure Electronics Flexible Conduit G Type Plastic Nylon Atex Cable Gland
-
Brass Metallic Waterproof Metric Type Cable Gland With Inner
-
China Supplier Stuffing Ip68 Vent Atex Brass Metal Pg Type Cable Gland
-
Waterproof Emc M75 Metric Type Atex Metal Brass Cable Gland Ip68
-
Ip68 Vent Flexible Conduit Adaptor Plastic G Size Cable Gland Manufacturer
-
Explosion Proof Cable Gland Ip68 Brass Metal Metric Type Pvc Free Sample M Type Compression Brass Cable Gland Nylon PA6 BEISIT
Product Description
M25 High Quality Beisit Best Waterproof Cable Gland
Exploded View of compression brass cable gland
Material: 1. Nickel Plated Brass for A,C,F parts
2. Nylon PA6 (Flammability UL 94-2) for D part
3. EPDM rubber for B parts, NBR rubber for E parts
Data Sheet of compression brass cable gland
| compression brass cable gland | |||||
| Model | Cable Range | H | GL | Spanner Size | Beisit No. |
| mm | mm | mm | mm | ||
| M 12 x 1,5 | 3-6,5 | 19 | 6,5 | 14 | M 1207BR |
| M 12 x 1,5 | 2-5 | 19 | 6,5 | 14 | M 1205BR |
| M 16 x 1,5 | 4-8 | 21 | 6 | 17/19 | M 1608BR |
| M 16 x 1,5 | 2-6 | 21 | 6 | 17/19 | M 1606BR |
| M 16 x 1,5 | 5-10 | 22 | 6 | 20 | M 1610BR |
| M 20 x 1,5 | 6-12 | 23 | 6 | 22 | M 2012BR |
| M 20 x 1,5 | 5-9 | 23 | 6 | 22 | M 2009BR |
| M 20 x 1,5 | 10-14 | 24 | 6 | 24 | M 2014BR |
| M 25 x 1,5 | 13-18 | 26 | 7 | 30 | M 2518BR |
| M 25 x 1,5 | 9-16 | 26 | 7 | 30 | M 2516BR |
| M 32 x 1,5 | 18-25 | 31 | 8 | 40 | M 3225BR |
| M 32 x 1,5 | 13-20 | 31 | 8 | 40 | M 3220BR |
| M 40 x 1,5 | 22-32 | 37 | 8 | 50 | M 4032BR |
| M 40 x 1,5 | 20-26 | 37 | 8 | 50 | M 4026BR |
| M 50 x 1,5 | 32-38 | 37 | 9 | 57 | M 5038BR |
| M 50 x 1,5 | 25-31 | 37 | 9 | 57 | M 5031BR |
| M 63 x 1,5 | 37-44 | 38 | 10 | 64/68 | M 6344BR |
| M 63 x 1,5 | 29-35 | 38 | 10 | 64/68 | M 6335BR |
Usage of compression brass cable gland

1.Introduction Of Company
Beisit Electric (Hangzhou) Co.Ltd.:
Beisit Electric Tech (Hangzhou) Co.,Ltd. is a leading manufacturer and supplier for high quality waterproof cable glands and and cable accessories, specializing in Design and manufacture strictly under the electrical standard of GB, IEC,EN and UL.
Beisit is considered to be innovative and partner for flexible application. With a strong tooling workshop and lab centre, the company is able to make quick response to customization request.
2.Factory View
3.Our Team
4.Certificates
5.Exhibitions
5.Why Choose US.
1. Compamy is Managed Strictly According to IATF16949/ISO9001.
2. Our strong technical team are established by high-end technical person that have reached 36%.
3. Strong Ability of Special Customization with a complete mold processing center.
4. Precision processing equipment are sourced from Japan, Korea and Taiwan to ensure that the products meet high precision requirement.
5. Capacity of Design and Manufacture of Precision Cutting Tools.
6. Advanced Testing Equipments. Products Tests fellow German Standard of DIN, VDE, American Standard of UL and comply with European Lastest Standard of EN and ATEX
Package
A. Common Packing: Certain Pcs + Zip Lock Bag + Label + Export Carton
B. Common Packing:Colorful Inner Box + Export Carton
C. Customized Packing: OEM Label, Inner Box, Blister, etc.
Delivery
A.By Courier: 4-7 Working days by special offer
B.By Air: 7 Working days at appointed airport
C.By Sea: 20-25 Working days at appointed port
