Vacuum Used Tray Grain Leaf Dryer Drying Dehydrator Machine Oven
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Food Dryer Machine/Vacuum Drying Oven With CE
-
China Factory Laboratory Medical Hospital Vacuum Drying Oven,Vacuum Drier,Vacuum Drying Closet
-
Vacuum Drier Sludge Drying Equipment Cassava Dryer Machine
-
High Level Digital Control Fruit Dehydrator 12 Stainless Steel Trays Pat Food And Fruit Dehydrator Baby Food Drying Machine
-
FL-60 Boiling Fluid Bed Dryer and Granulator With Spray System for Solid Granule Infusion Drink Milk Coffee Juice Stevia Powder
-
Low Dosage Allowed Bullet Sgape Supposity Fillling Machine Manufacture With Better Service and Engineer Available
Product Description
Product Description



CT-C series hot air circulation drying oven uses a low noise and high temperature proof axial flow blower and an automatic temperature control system. The whole circulation system is the fully enclosed to make that the heat efficiency of the drying oven increases from 3-7% of the traditional drying oven to 35-45% of the present one. The highest heat efficiency can reach 50%. The successful design of CT- Chot air circulation drying oven makes that the hot air circulation drying oven in our country reach the advanced level both at home and abroad. In order to save a large quantity of the energy in our country, in order to enhance the economic results of the enterprises, in 1990, the medicine management bureau of the State issued the industry standard and the uniform type is RXH.
Detailed Images



Technical Parameters

Model of industrial standard | RXH-5-C | RXH-14-C | RXH-27-C | RXH-41-C | RXH-54-C |
Model specification | CT-C-0 | CT-C-I | CT-C-II | CT-C-III | CT-C-IV |
Dry amount each time (kg) | 60 | 120 | 240 | 360 | 480 |
Equipped power (kW) | 0.45 | 0.45 | 0.9 | 1.35 | 1.8 |
Consumption of steam (kg/h) | 10 | 18 | 36 | 54 | 72 |
Area of radiation(㎡) | 10 | 20 | 40 | 80 | 100 |
Amount of air (m³/h) | 3450 | 3450 | 6900 | 10350 | 13800 |
temperature difference between up and low(°C) | ±2 | ±2 | ±2 | ±2 | ±2 |
Amount of drying tray to be equipped | 24 | 48 | 96 | 144 | 192 |
Overall dimensions WxDxH(mm) | 1480*1100 *1750 | 2300*1200 *2000 | 2300*2200 *2000 | 2300*3200 *2000 | 4460*2200 *2290 |
Equipped drying trolly | 1 | 2 | 4 | 6 | 8 |
Product Application



Applications
1.The heat source can be steam, heat conductive oil,electricity or far infrared. Customers can select one of them in accordance with practical conditions.
2.Temperature for steam:140℃-150℃.
3.Temperature for electricity or far infrared:350℃.
4.There are automatic and computer control system for customers to choose.
5.The normal steam pressure:0.2-0.8MPa.
6.Power for electricity heat source will be 15KW calculated as Model I. Practical power to be used will be 5-8kw/h.
7.lf any special requirements, please indicate it when order.
8. Parameters for non-standard ovens shall be discussed separately according to different conditions.
9.If the operating temperature is higher than 14℃ or lower then 60℃, please indicate it when order.
10.The drying trollies and trays are of a standard size and can be exchanged with one another.
11.The size of drying tray:460x 640x45mm.
The radiators can be used for various drying equipment.There are many specifications and kinds.The materials to be used are aluminium alloy stainless steel, A3 steel surface zinc covering,steel and aluminium compound, copper,steel pipe and aluminium winding sheet In addition.the radiators can be used for the heating and dehunidification indoors in the warehouses.Our factory can carry out the design and manufacturing for our users.
