Product Description
CRS-718C CR/ EUI/EUP /HEUI injector test bench
common rail tester EPS815 China fuel pump test bench
Product Description
common rail injector tester,
common rail injection pump test bench,
CRS-718C
CRS-718C test bench can test common rail pump & injector & piezo injector.
It test by flow sensor with more precise and stable measurement.
It can add EUI/EUP, C7/C9 test system to this machine(optional).
The data is obtained by computer.
19" LCD screen display.
Please scan the QR code,watch test bench using video
Characteristic
| Main drive adopts the speed change by frequency change. |
|
Controlled by industrial computer in real time, Windows operating system.
Fulfill the remote assistance by internet and make the maintenance easy to operate.
|
| Injector oil quantity is measured by high precise sensor and displayed on 19 LCD |
| Drive signal can be adjusted |
| Percentag e of drive signal can be adjusted. |
| Rail pressure can be tested in real time and controlled automatically, it contains the high-pressure protection function. |
| Data can be searched, printed and made into database. |
| Pulse and frequency of the injector drive signal can be adjusted. |
| injection time can be setted. |
| Protection function of short-circuit. |
| Oil temperature is controlled by forced-cooling system. |
| Plexiglass protective door, easy operation, safe protection. |
| Measure the flux of common rail pump by flow meter sensor. |
Functions
|
Common Rail Injector
|
Common Rail Pump
|
|
1. test brands: all common rail injector
|
1. test brands: all common rail pump
|
|
2. test 1 piece of injectors at a time.
|
2. test the sealing of common rail pump.
|
|
3. test the max. oil quantity of high-pressure common rail injector.
|
3. test the internal pressure of common rail pump.
|
|
4. test the cranking oil quantity of high-pressure common rail injector.
|
4. test the proportional electromagnetic valve of common rail pump.
|
|
5. test the backflow oil quantity of high-pressure common rail injector.
|
5. test the input pressure of common rail pump.
|
|
6. test the average oil quantity of high-pressure common rail injector.
|
6. test the flux of common rail pump.
|
|
7. set the high-pressure common rail injector's injection state and oil quantity measurement.
|
7. measure the rail pressure in real time.
|
|
8. Data can be searched, printed and made into database.
|
8. Data can be searched, printed and made into database.
|
Test photos
« « Test CP3 Pump
Test Common rail injector » »
« « Test EUI/EUP
Test HEUI injector » »
« « Test HP0 Pump
Detailed Images
Technical Parameters
|
Injection testing frequency
|
50~3000 rpm
|
|
Pulse width
|
0.1~200 ms
|
|
Continuous injection times
|
0~1000
|
|
Fuel temperature
|
40±2°C
|
|
Supply oil quantity of common rail injector
|
0~200cc/min 0.5%
|
|
Rail high pressure
|
0~1800 bar
|
|
Test oil filtered precision
|
5μ
|
|
Input power
|
380V/50hz/3phase or 220V/60hz/3phase
|
|
Rotation speed
|
0~4000RPM
|
|
Oil tank capacity
|
60L
|
|
Flywheel inertia’s moment
|
0.8KG.M2
|
|
Center height
|
125MM
|
|
Output power
|
11KW
|
|
Overall dimension(MM)
|
1600×650×1300
|
|
Weight
|
1000 kg.
|
Payment & Shipping
We can accept T/T
Delivery Time:10-15days after received your payment.
Packaging Details:Plywood case.
Contact us
If you need anything,Please don't hesitate to contact with me.
Taian Sunshine International Trading Co., Ltd
Contact : Edward Nie
QQ/Wechat:1877054430
Mob/whatsapp:+8615864005110
Skype:+8615864005110
Tel:+86-538-6122577
|
