Home > Products > Comsumer&Electronics > CZE-7C 1W 7W Stereo LCD Broadcast Radio Station Home Wireless Audio System FM Transmitter
CZE-7C 1W 7W Stereo LCD Broadcast Radio Station Home Wireless Audio System FM Transmitter
- T/T Credit Card
You May Like
-
12V 20W FM Transmitter Stereo PLL Broadcast Radio Station +Range Max Antenna+Power
-
20 Pagers Electronic Wireless Queuing Calling System for Food Coffee Shop Hospital Bank
-
Restaurant 20 Pagers DC 5V Power Supply Coaster Pagers Wireless Coaster Guest Waiter Queuing System
-
80x80mm X Axis Trimming Station Micrometer Manual Displacement Platform Manual Linear Stage
-
110V 220V 0-8000R 350W Leather Burnishing Polishing Machine Leather Burnisher Machine
-
GPSDO GPS Clock 10M LCD Display Frequency Message Disciplined Oscillator
Product Description
CZE-7C 1W 7W Stereo LCD Broadcast Radio Station Home Wireless Audio System FM Transmitter
Parameters :
- Dimensions : L * W * H / 12.5 * 9.5 * 5.5 ( unit : cm; excluding protrusions)
- Power supply voltage : DC12V
- Operating Current : <1.5A
- Frequency range : 76 ~ 108M
- Frequency Step : 0.1M
- Frequency stabilization mode : PLL Frequency Synthesizer
- Modulation : FM Stereo
- Deviation : +/- 75K
- Pre-emphasis Delay : 50us
- S / N ( stereo ): >40db
- Stereo separation : -45dB (5000Hz ~ 15000Hz)
- Frequency response : 40K ~ 15K -+0.2dB ( stereo )
- Distortion: <0.3%
- Modulation : 15%
- Input Level : -15dBV
- RF output impedance : 50 Ohm
Features:
- Stereo LCD, 1W and 7W can be switched
- Adjustable 76M-108M
- Good radiation and stable power
Note: below is the cover distance of the FM transmitter
0.2W-0.5W ideal distance 200-500 meters
1/7W Ideal distance 1-2 KM
15W ideal distance 2-3 KM
25W ideal distance 5-8 KM
50W ideal distance 8-12 KM
Package included:
- 1 x FM Transmitter
- 1 x Power supply
- 1 x Audio cable
- 1 x Antenna
Detail photo

FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Samples arrived often need 3-5 days.
Q3. Do you have any MOQ (minimum order quality)limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions. Thirdly, customers confirms the samples and places deposit for formal order. Finally, We arrange the production.
Q6. Is it acceptable to print my logo on the product?
A: Yes. Please inform us formally before our product and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer one-year warranty for our products.
Q8: How to deal with the flaw?
A: Our products are produced in strict quality control system and the percent of pass is often maintained over 99.8%
Packing&Shipping
Package: Normally we use the standard exporting packaging. We also can according to clients' request .
Shipping :
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier we are co-operating at present.
2. By Air: Delivery from the Shanghai airport to customers’ destination city air port.
3. By Sea: Delivery from the Shanghai sea port .
Company information
TZT has been speciliazing in Business & Industry,Hobbies & Toys,CNC Products and Health care supplies for over 5 years.We committed to enhance customer satisfaction by continually improving the process with a vision of expertise in the field.
Aiming to provide high quanlity products and great service for buyer,we are strict on product quanlity control and offer instant communication service.Welcome to contact us!
Our Advantages:
- Source only the best consumer goods and ensure the highest quality.
- Streamline the buying and payment process, and make it as easy as possible.
- Help the customers all over the world discover products and manufacturers in China.
- The Shortest order processed time and speed delivery
Contact Us
- Shenzhen Tianzhongtian Trading Co., Ltd.
