GL Lower Price Wholesales 24/48/96/144/288 ADSS Fiber Optic Cable With 50-150 Span
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
GL Telecommunication Use ADSS 24 Cores Single Mode Fiber Optic Cable 48 Threads With One Tube HDPE Jacket and FO Number of Tube
-
GL Outdoor Antena Autosuficiente Cable de Fibra Optica Adss 24 Core Aerial Fiber Optic Cable Price Cable Fiber Optic
-
GL Factory Manufacturers Fiber Optic Cable Adss Hot Sale List Price Double Sheath 6 12 24 48 Core Outdoor Fiber Optic Cable
-
GL Factory Price Outdoor Self-supporting Aerial Fibra Optica Adss 12 Core 24 Core Span 100m Adss Fiber Optic Cable
-
GL Manufacturer Supply High Quality GYTC8S ADSS OPGW GYXTW-4 GYTA FTTH Fiber Optic Cable Price per Meter
-
12 24 96 Core Adss Cores Price 48 Optical Aerial G652d Fibre Self Supporting Outdoor Optic Fiber Cable
Product Description
Product Description
Fiber count | 12 |
Max. No of loose tube / filler No. | 4/2 |
Number of fiber in tube | 6 |
Gel filled in Loose tube | Yes |
Central strength member | FRP |
Water blocking material | filling gel in cable |
Outer sheath thickness | 1.8-2.0mm |
Outer sheath material | HDPE |
Cable OD(mm)Approx | 10.5±0.2mm |
Cable weight (kg/km) | 81 |
Operation temperature range | -40 ℃to + 70 ℃ |
Installation temperature range | -40 ℃to + 70 ℃ |
Transport and storage temperature range | -40 ℃ to + 70℃ |
Span | 100m |
Suitable for lines | ≤35KV If the cable will be used on the more than35KV,the Outer Sheath material must be Anti-tracking (AT) |
Rated tensile strength (KN) | 1.2 |
Maximum allowable tensile(KN) | 0.5 |
Crush resistance | Installation :2200 (N/100mm) Operating :1100N/100mm |
Minimal installation bending radius | 20 x OD |
Minimal operation bending radius | 10 x OD |
The fibres shall be marked by a coloured coating with 12 different colours according to EIA/TIA 598:
Get One Stop Service
Click to "Contact" Us
One-to-one Service
We provide One to One Customized Service for you 24 hours online.
We are here to help you achieve your network goals. Whether that is through network design, detailed engineering, construction or management of your project, GL has the experience to help make your network upgrade a success.
Why Choose Us
Related Products
Packing&Shipping
Company Introduction
FAQ
1.Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.
2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.
5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.
Us. We are the real manufacturer with 15 year’s history.
2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.
5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.
