Cheap Price Self-Supporting Flat Drop Aerial Fiber Optic Cable GYFXTY-FL
Product Description
The fibers are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of water blocking system. Two parallel FRP are placed at the two sides. The cable is completed with a polyethylene (PE) sheath.
Optical Characteristics:
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation (+20℃) | @850nm | ≤3.0dB/km | ≤3.0dB/km | ||
| @1300nm | ≤1.0dB/km | ≤1.0dB/km | |||
| @1310nm | ≤0.36dB/km | ≤0.40dB/km | |||
| @1550nm | ≤0.22dB/km | ≤0.23dB/km | |||
| Bandwidth(Class A) | @850nm | ≥500MHz·km | ≥200MHz·km | ||
| @1300nm | ≥1000MHz·km | ≥600MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.15NA | |||
| Cable Cut-off Wave length | ≤1260nm | ≤1480nm | |||
Structure and Technical Specifications OF GYFXTY :
| Fiber count | Cable diameter(mm) | Nominal weight(KGS) | Allowable Tensile Load(N) | Allowable Crush Resistance(N/100m) | ||
| Short term | Long term | Short term | Long term | |||
| 2-12 | 6.0-9.0 | 60 | 800N | 400N | 1000N/100m | 300N/100m |
Feature:
Good mechanical and temperature resistant performance.
Uni-tube gel-filled construction for superior fiber protection.
Two parallel steel wires ensure tensile strength.
PE sheath protects cable from ultraviolet radiation.
Light weight and small diameter, easy to installation and operation.
Application:
Overhead/Duct.
