Plastic Crane Outrigger Pads Engrave Company Name PE Truck Panel Crane Stabilizer Pad Outrigger Pads for Boom Truck
- Qingdao or Tianjin Port China
- T/T Credit Card
You May Like
-
Heavy Load Capacity Round Uhmw Outrigger Pad/ Crane Foot Bearing Support/ Anti-impact Crane Stabilizer Pad
-
UHMW PE Crane Foot Bearing Support/UHMW PE Crane Outrigger Pads/UHMW PE Crane Mats Pads, UHMWPE Crane Mat
-
Hdpe Outrigger Pads/ UHMW Crane Leg Support Pads/ Temporary Roadways, Flat Portable Plastic pe Outrigger Pads Uhmw Crane Pad pe
-
Hot Sale Mobile Cranes/Wear Resist Jack Leg Levelling/temporary Outrigger Pads Product, Crane Stabiliser Pad/panel/board
-
Crane Stabiliser Pad Crane Foot Pad Mobile Truck Crane Stabiliser Pad
-
Anti-UV Jack Support Boards/strong PE Crane Mat/ Wear Resistant Outrigger Pad, Ground Mat Made of 100% HDPE
Product Details
| Brand Name | Xinxing | Place of Origin | Shandong, China | |
| Model Number | xxpe0001-51 | Material | PE | |
| Size | cut to size as your need | Thickness | 10-300mm |
Product Description
Plastic crane outrigger pads engrave company name PE truck panel
Why Choose Us
l More than 15 years' professional manufacturing experience with own factory.
l Virgin 100% material produced, high quality with good surface and color make ensured
l GB/T 19001-2008 ; ISO 9001:2008 certification.
l Competitive price, In stock, Fast delivery, and Excellent service.
l OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.
The properties of HD-PE outrigger pads:
Property | Unit | Value |
Density | g/cm3 | 0.93-0.96 |
Average molecular weight | g/mol | 3million- 10 million |
Tensile strength (23°C in air) | MPa | 22 |
Breaking strength | MPa | 42 |
Tensile strain at break | % | 600 |
Charpy impact strength (notched) | mJ/mm2 | No break |
Ball indentation hardness | N/mm2 | 42 |
Shore D hardness | -- | 65-70 |
Abrasion | % | 70-80, steel = 100 |
Static Friction Coefficient | -- |
≤0.16 |
Kinetic Friction Coefficient | -- |
≤0.10 |
Water Absorption | -- | NIL |
Elongation at break at 23 degress | % | ≥300 |
Temperature resistance | °C | -269 to +85 |
Melt Temperature | °C | 130-140 |
Our HD-PE outrigger pads Characters:
1.very flat on the surface
2.The thickness tolerance is +2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.
5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.
6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.
XinXing outrigger pads
are made in UHMWPE, an engineering material that offers a superior combination of impact strength, wear and chemical resistance. Each pad is equipped with a durable wire handle to allow for easy storage and mobility.
PE Outrigger Pads are an alternative to wood pads due to their superior characteristics and performance which allows them to last longer.
Max. Load:350 MT
Feature: Square with rope handle, Convex mark face (skid-proof)
Both virgin and recycled UHMWPE outrigger pads is available
XINXING provides a very strong, durable, and cost-effective footing for all your our Outrigger Pads applications.
XINXING outrigger pad is made of PE material
Because PE material has the following advantage :
--Highest abrasion resistance of any polymer, 6 times more abrasion resistant than steel
--Do not absorb moisture and will not swell up over time due to exposure outdoors.
--Good impact intensity,Do not lose their impact strength over time.
--Good breaking elongation,so they will bend but not break under extreme loads.
--Non-stick surface, easy to clean.
--Corrosion and chemical resistant.
--Noise- absorption, Vibration-absorption
--Super compression strength
--15 Percent the weight of steel pads and easier to handle
--Compressive loads up to one million pounds
--Up to 15,000 pounds per square foot
--Non-Conductive
--Non-Toxic and smell
Benefits:
--Work in sub zero temperatures
--Easy to mount, replace
--Reduced downtime.
--Lower maintenance costs.
--Storage-Friendly
--Durable & Long Lasting
--Cost Efficient compared to Steel or Aluminum
--Safer to use in the field compared to other wood based pads.
Our standard outrigger pads size:
| Dimensions(mm) Square | Weight(kg) | Vertical Jack Capacity (tonne) | Crane Capacity(tonne) |
400*400*40 | 6.3 | 10 | 12 |
| 500*500*40 | 9.9 | 12 | 15 |
| 600*600*40 | 14.2 | 20 | 20 |
| 700*700*40 | 19.4 | 22 | 30 |
| 800*800*40 | 25.3 | 25 | 30 |
| 1000*1000*40 | 39.2 | 30 | 35 |
| 400*400*50 | 8 | 11 | 15 |
| 500*500*50 | 12.2 | 15 | 18 |
| 600*600*50 | 18 | 23 | 30 |
| 800*800*50 | 31.3 | 30 | 35 |
| 1000*1000*50 | 48 | 40 | 50 |
| 400*400*60 | 9.5 | 12 | 15 |
| 500*500*60 | 14.5 | 20 | 25 |
| 600*600*60 | 21.2 | 25 | 30 |
| 800*800*60 | 38.4 | 35 | 45 |
| 1000*1000*60 | 58.5 | 50 | 65 |
| 1200*1200*60 | 85 | 70 | 80 |
| 800*800*70 | 44 | 40 | 50 |
| 1000*1000*70 | 68.5 | 70 | 80 |
| 800*800*80 | 50.4 | 50 | 60 |
| 1000*1000*80 | 78 | 80 | 100 |
| 1200*1200*80 | 113 | 100 | 120 |
| 1000*1000*80 | 98 | 110 | 140 |
| 1200*1200*100 | 141 | 140 | 160 |
Any small size need us to cut , we can satisfy your special need .
Other products:
Our machinery
Our factory
our lab
Packaging : pallet packing or as client need.
XINXING can provide various UHMWPE & HDPE products with the good quality at reasonable price according to your requirement.
Any questions, please feel free to contact us.
thanks for you visit us !
