UHMWPE Crane Outrigger Pad, Mobile Truck Crane Spare Part of Crane Outrigger Pad
- Qingdao Port or Qingdao Port
- T/T Credit Card
You May Like
-
Crane Sleeper UHMW PE Pad,hdpe Plastic,uhmwpe Crane Outrigger Pads
-
Positioning Jack Pads for Heavy Crane Construction,hdpe Plastic,uhmwpe Crane Outrigger Pads
-
UHMWPE Crane Outrigger, Uhmwpe Hdpe Crane Outrigger Pad 500x500x40mm Mobile Truck Crane Outrigger Pad in Good Price and Quality
-
Uhmwpe/hdpe Outrigger Pad 900 x 900 x 50mm Outrigger Pad Price
-
Heavy Duty Large Plastic HDPE Track Mats
-
Blue Temporary Mobile HDPE Access Road Mat Anti-Slip Plastic Plate
Product Details
| Brand Name | XINXING | Place of Origin | Shandong, China | |
| Model Number | SDXXHG1771 | Material | PE | |
| Size | all size available | Thickness | 6-300mm |
Product Description
UHMWPE crane outrigger pad, mobile truck crane spare part of crane outrigger pad
(1)
Xinxing Outrigger Pads are manufactured using engineered UHMW polyethylene, providing superior strength-to-weight ratio than the timbers commonly used to support outriggers and crane arms. These lightweight, reusable pads provide a large non-slip surface area for absorbing load - minimising movement and sinkage. They can be used to stabilise outriggers, crane arms, scaffolding structures, uprights and angled loadings.
Xinxing Outrigger Pads will not splinter, warp, delaminate or breakdown in the harsh environment. The pads are engineered to bend but not break and come with a Lifetime Replacement Guarantee. Featuring a non-slip textured surface, these pads are built to the highest safety standards and are very easy to use with convenient orange safety rope handles.
Xinxing Outrigger Pads are the only engineered quantifiable and rated outrigger pads available today and come in a range of sizes to suit every job.
Notes
- Foot pads must be smooth and have 203.2 sq. cm of surface.
- Muddy or loose soil conditions may require additional shoring or stacking of pads.
- Excessive flexing &/or bending may shorten the usable life of the pad.
- Acceptable operating temperature range is -40°C to 82.2°C.
- Handle located on width side of all pads, larger pads have two or more handles opposite each other.
STANDARD SIZES:
|
|
Size |
Load Capacity Vertical |
Load Capacity 45° Angle |
Weight Per Pad |
|
PAD |
380 x 380 x 20mm |
20.4Tonne |
9Tonne |
3kg |
|
PAD |
450x 450 x 25mm |
24.9Tonne |
13.6Tonne |
5kg |
|
PAD |
600 x 600 x 25mm |
27.2Tonne |
15.8Tonne |
9kg |
|
PAD |
600 x 600 x 50mm |
28Tonne |
18Tonne |
17kg |
SPECIAL SIZES:
|
|
Size |
Load Capacity Vertical |
Load Capacity 45° Angle |
Weight Per Pad |
|
PAD |
760 x 760 x25mm |
36.7Tonne |
18.5Tonne |
14kg |
|
PAD |
760 x 760 x 50mm |
38.5Tonne |
19.5Tonne |
28kg |
|
PAD |
900 x 900 x 25mm |
42Tonne |
19.5Tonne |
20kg |
|
PAD |
900 x 900 x 50mm |
44.25Tonne |
20.41Tonne |
40kg |
|
PAD |
1200 x 1200 x 25mm |
61Tonne |
23.5Tonne |
36kg |
|
PAD |
1200 x 1200 x 50mm |
63.5Tonne |
24.94Tonne |
72kg |
(2) Relevant UHMW-PE crane outrigger pad pictures
UHMW-PE crane outrigger pad in black color
HDPE crane outrigger pad in black color
PE crane outrigger pad in black color
UHMW-PE/HDPE crane outrigger pad in black color
(3) yellow color PE crane outrigger pad properties
--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
--Anti-Weather & Anti-Aging
--Self-lubricating, Very low coefficient of friction
--Excellent chemical & corrosion resistant
--superior impact resistant, Noise- absorption, Vibration-absorption
--High tensile Strength
--Non-Toxic and smell
--UV resistance
--Flame Retardant; Relatively low in water absorption
--Excellent electrical properties
--Good performance in resisting environment stress crack, 200 times of ordinary PE
--No adhesion
--Light weight and easier to handle and fix
--Cost efficient; Resulting in low energy consumption
--Does not rot, split or crack; 100% recyclable
--Great liner material for industrial material handling applications
--Easy Reprocessed plastic ground protection mat
-Creats an instant roadway over virtually any type of terrain – mud, sand, marshy, uneven or soft terrain
- Extremely durable to withstand vehicle weights up to 80 tons
- Tested in extremes of hot and cold climates
(4) PE crane outrigger pad in different shape
Standard Rectangular Models of PE crane outrigger pad
- 600 x 600 thickness 40mm, weight 15kg/peice
- 750 x 1000 thickness 50mm, weight 38kg/peice
- 1000 x 1200 thickness 60mm, weight 72kg/peice
- 1000 x 1200 thickness 80mm, weight 96kg/peice
Standard Round Models - new sizes of PE crane outrigger pad
- 800mm thickness 50mm, weight 25kg/peice
- 900mm thickness 60mm, weight 38kg/peice
- 1000mm thickness 80mm, weight 62kg/peice
- 1200mm thickness 60mm, weight 68kg/peice
- 1200mm thickness 80mm, weight 95kg/peice
(5) Company advantages
1.the quantity of our presses is the most in UHMWPE industry
2.have a long history of nearly twenty years,so we have rich experience and technology in UHMWPE industry.
3.we designed the presses by ourselves with special two machines recycled which can reduce the time production.
4.we have our own laboratory,have the most excellent sales people,have our own technique department and supplies products all over the world to many large customer.
UHMWPE Certificate
UHMWPE Production steps
UHMWPE Testing equipment
Contact details
