12v volt manual electric stacker power unit wholesale lateral horizontal

 12v volt manual electric stacker power unit

wholesale lateral horizontal

General Description:

This POWER UNITS FOR MANUAL ELECTRIC STACKER is designed exclusively for the forklift, consist of high pressure gear pump,DC motor,multifunctional manifold ,valves ,tank,etc.
The up and down movement are controlled by the level of the mannal release valve ,which is equipped with an electric switch for the motor start . The lowering speed is automatically adjusted by the pressure compensated flow control valve.

SPECIAL NOTES:

1. The duty of this power unit is S3,i .e.,30 seconds on and 270 seconds off.
2.Clean all the hydraulic parts concemed before mounting the power unit.
3. Viscosity of the hydraulic oil should be 15-68 cst,which should also be clean and free of impurities. N46 hydraulicoil is recom-mended.
4.This power units should be mounted horizontal.
5.Check the oil level in the tank after the first start of the power unit.
6.Oil changing is required after the initial 100 operation hours afterwards once every 3000 hours.

12V 800W 3650 RPM

PALLET TRUCK POWER UNITS

1.12v 0.8kw 3650rpm 0.5cc/r

2.12v 0.8kw 3650rpm 0.75cc/r

3.24v 0.8kw 3650rpm 0.5cc/r

4.24v 0.8kw 3650rpm 0.75cc/r

MINI POWER UNITS FOR MEDICAL CARE EQUIPMENT

POWER UNITS FOR MANUAL ELECTRIC STACKER

1.12V 0.8KW 3650RPM 0.5CC/R

2.24V 0.8KW 3650RPM 0.5CC/R
