Product Details
| Brand Name | shuangjia | Place of Origin | Henan, China | |
| Model Number | conductor | Type | High Voltage | |
| Application | Overhead | |||
| Conductor Material | Aluminum |
Product Description
Application
All aluminum alloy stranded conductor cable are used in power transmission and distribution lines with various grade voltages.
Standard
GB1179,IEC61089,BS3242,DIN48201,ASTMB399 etc.
Main Characteristics:
Strength--- About twice that of aluminium 1350(EC)
Weight---- Approximately 20% lighter than ACSR conductor of equal diameter
Corrosion resistance --It has a high resistance to atmospheric corrosion which is suitable for coastal and industrial areas.
Surface hardness--AAAC's surface is significantly harder than aluminium 1350. It is less liable to damage during installation which is
an important advantage of EHV transmission lines where corona and radio interference is a major consideration.
Termination ---- Much simpler jointing accessories required compared to ACS
AC Resistance---- AAAC is a non-magnetic material. It does not exhibit the magnetic core losses found in ACSR
Technical parameters:
IEC 61089
Code Number | Stranding&wire diameter | Approx Overall diameter | Nominal area | Approx. Weight | Breaking Load | DC Resistance at 20 |
mm | mm | mm2 | Kg/km | KN | Ohm/km | |
16 25 40 63 100 125 160 200 250 315 400 450 500 560 630 710 800 900 1000 1120 1250 | 7/1.83 7/2.29 7/2.89 7/3.63 19/2.78 19/3.10 19/3.51 19/3.93 19/4.39 37/3.53 37/3.98 37/4.22 37/4.45 61/3.67 61/3.89 61/4.13 61/4.38 91/3.81 91/4.01 91/4.25 91/4.49
| 5.49 6.86 8.68 10.9 13.9 15.5 17.6 19.6 22.0 24.7 27.9 29.6 31.2 33.0 35.0 37.2 39.5 41.8 44.1 46.7 49.4 | 18.4 28.8 46.0 72.5 115 144 184 230 288 363 460 518 575 645 725 817 921 1036 1151 1289 1439 | 50.4 78.7 125.9 198.3 316.3 395.4 506.1 632.7 790.8 998.9 1268.4 1426.9 1585.5 1778.4 2000.7 2254.8 2540.6 2861.1 3179.0 3560.5 3973.7 | 5.43 8.49 13.58 21.39 33.95 42.44 54.32 67.91 84.88 106.95 135.81 152.79 169.76 190.14 213.90 241.07 271.62 305.58 339.53 380.27 424.41 | 1.7896 1.1453 0.7158 0.4545 0.2877 0.2302 0.1798 0.1439 0.1151 0.0916 0.0721 0.0641 0.0577 0.0516 0.0458 0.0407 0.0361 0.0321 0.0289 0.0258 0.0231 |
