10kn Soil Light-duty Triaxial Test Apparatus
- Qingdao China
- T/T Credit Card
You May Like
-
Manual Dumbbell Tensile Test Specimen Cutter
-
JJ-5 Cement Mortar Mixer
-
Bonding Strength Tester/ Universal Testing Machine+Wood Testing Equipment
-
Intelligent Electric Tetragenous Direct Shear Testing Machine / Soil Lab Testing Equipment
-
Manual Die Cutter Used for Making Rubber Sample
-
ASTM Standard Tensile Test Specimen Cutter
Product Details
| Brand Name | Hensgrand | Place of Origin | Shandong, China | |
| Model Number | HST | Power | Electronic |
Product Description
10kn Soil Light-duty Triaxial Test Apparatus
Application:
Bench Lightduty Triaxial aTest Apparatus is designed for laboratory and educational
use as well as institute for civil engineering test. It is a type of strain controlled apparatus to determine the specimen with maximum confining pressure of 1Mpa and sample diameter of Φ39.1x80mm. It can perform the strength and deformation characteristics testing of soil specimen under the static axial load and unconsolidated-undrained test (UU), consolidated-undrained test (CU) and consolidated-drained (CD) test.
Specimen: |
Φ39.1mm X 80mm |
Capacity: |
10KN maximum 10KN |
Strain rate: |
0.016-1.6mm/min. mechanical speed with 6 gears |
Platen travel: |
50mm maximum |
Confining pressure:(σ3) |
0-1MPa |
Anti-pressure:(σb) |
0-0.6MPa |
Pore pressure:(u) |
0-1MPa |
Volume deformation: |
0-25ml,minimum division:0.1ml |
Axial displacement: |
0-30mm(micrometer) |
Power supply: |
220V±10% 50Hz |
Dimension: |
Main unit:350 x 300 x 1100mm(L x W x H) |
Weight: |
170Kg |
10kn Soil Light-duty Triaxial Test Apparatus
