60kn Soil Triaxial Shear Test Machine
- Qingdao China
- T/T Credit Card
You May Like
-
Full Automatic Triaxial Test Apparatus / Civil Engineering Equipment
-
10kn Soil Light-duty Triaxial Test Apparatus
-
Manual Dumbbell Tensile Test Specimen Cutter
-
JJ-5 Cement Mortar Mixer
-
Bonding Strength Tester/ Universal Testing Machine+Wood Testing Equipment
-
Intelligent Electric Tetragenous Direct Shear Testing Machine / Soil Lab Testing Equipment
Product Details
| Brand Name | Hensgrand | Place of Origin | Shandong, China | |
| Model Number | HST | Power | Electronic | |
Product Description
60kN Triaxial Infinitively Variable Speeds Shear Test Machine Application: |
The Apparatus is used to determine the resisting shear strength of the soil specimen with maximum confining pressure of 2.0MPa and specimen dimension is of Φ61.8x125mm,Φ101x200mm. The apparatus can perform unconsolidated-undrained shear test (UU),consolidated-undrained shear test (CU), and consolidated-drained (CD) shear test. It consists of frame, test control device,pressure chamber and specimen tools etc. |
Specimen: |
Φ39.1mm x 80mm, Φ61.8mm x 125mm, Φ101mm x 200mm |
Capacity: |
60KN |
Strain rate: |
0.0001-4.8mm/min. |
Platen travel: |
0-100mm |
Confining pressure: |
0-2MPa Digital control and display |
Back pressure: |
0-1MPa Digital control and display |
Pore pressure:(u) |
0-2MPa |
Volume deformation: |
0-100ml,minimum resolution:0.2ml |
Power supply: |
220V±10% 50Hz |
Weight: |
240Kg (including main unit,controller,measuring equipment etc.) 60kn Soil Triaxial Shear Test Machine
|
