KF160XPO/KF160ARO China Thin Section Bearings for Packaging equipment
USD $1 - $100000
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- shanghai
- T/T L/C D/P D/A PayPal Cash Other
- 7 days
You May Like
-
KD160XP0/KD160ARO China Thin Section Bearings for Aerospace and defense
-
KA020XP0/KA020ARO china thin section bearings 2x2.5x0.25inch Thin-wall Bearing S-upplier Stock
-
VLU200844 734x948x56mm Four point contact slewing bearings China bearing custom made
-
VLU200414ZT VLU200414 Four point contact slewing bearings China bearing custom made
-
VLU200544ZT VLU200544 Four point contact slewing bearings China bearing custom made
-
VLU200644 ZT VLU200644 Four point contact slewing bearings China bearing custom made
Product Details
| Brand Name | OEM | Place of Origin | China | |
| Model Number | KF160CP0 | Number of Row | Single Row | |
| Seals Type | open | Precision Rating | P5 | |
| Outside Diameter | 5, 200 | Bore Size | 5, 150 |
Product Description
kaydon thin-section bearings Structure
Open type deep groove ball bearing
Open type angular contact bearing
Open type four point contact bearing
Sealed type deep groove ball bearing
Sealed four point contact ball bearing
Parameters
| YDKFSeries | Interchange | Boundary dimensions (inch/mm) | Basic Cap.N | Weight | ||||||||
| Radial | Axial | |||||||||||
| Bearings Type | NTN | KAYDON | d | D | H | L1 | L2 | Cor | Cr | Coa | Ca | Kg |
| YDKF080XP0 | KXF080 | KF080XP0 | 8 | 9.5 | 0.75 | 8.555 | 8.945 | 43920 | 29050 | 109750 | 456010 | 1.66 |
| 203.2 | 241.3 | 19.05 | 217.3 | 227.2 | ||||||||
| YDKF090XP0 | KXF090 | KF090XP0 | 9 | 10.5 | 0.75 | 9.555 | 9.945 | 48900 | 30880 | 122280 | 49030 | 1.81 |
| 228.6 | 266.7 | 19.05 | 242.7 | 252.6 | ||||||||
| YDKF100XP0 | KXF100 | KF100XP0 | 10 | 11.5 | 0.75 | 10.555 | 10.945 | 53920 | 32630 | 134820 | 52320 | 2.02 |
| 254 | 292.1 | 19.05 | 268.1 | 278 | ||||||||
| YDKF110XP0 | KXF110 | KF110XP0 | 11 | 12.5 | 0.75 | 11.555 | 11.945 | 58940 | 34320 | 147350 | 55520 | 2.18 |
| 279.4 | 317.5 | 19.05 | 293.5 | 303.4 | ||||||||
| YDKF120XP0 | KXF120 | KF120XP0 | 12 | 13.5 | 0.75 | 12.555 | 12.945 | 64960 | 35930 | 159890 | 58630 | 2.38 |
| 304.8 | 342.9 | 19.05 | 318.9 | 328.8 | ||||||||
| YDKF160XP0 | KXF160 | KF160XP0 | 16 | 17.5 | 0.75 | 16.555 | 16.945 | 84010 | 41880 | 210070 | 70320 | 3.22 |
| 406.4 | 444.5 | 19.05 | 420.5 | 430.4 | ||||||||
| YDKF180XP0 | KXF180 | KF180XP0 | 18 | 19.5 | 0.75 | 18.555 | 18.945 | 94060 | 44570 | 235140 | 75830 | 3.58 |
| 457.2 | 495.3 | 19.05 | 471.3 | 481.2 | ||||||||
| YDKF250XP0 | KXF250 | KF250XP0 | 25 | 26.5 | 0.75 | 25.555 | 25.945 | 129180 | 52930 | 322950 | 93660 | 4.95 |
| 635 | 673.1 | 19.05 | 649.10 | 659.00 | ||||||||
| YDKF300XP0 | KXF300 | KF300XP0 | 30 | 31.5 | 0.75 | 30.555 | 30.945 | 154250 | 58070 | 385670 | 105440 | 5.9 |
| 762 | 800.1 | 19.05 | 776.10 | 786.00 | ||||||||
| YDKF400XP0 | KXF400 | KF400XP0 | 40 | 41.5 | 0.75 | 40.555 | 40.945 | 204430 | 66830 | 511200 | 127220 | 7.81 |
| 1016 | 1054.1 | 19.05 | 1030.10 | 1040.00 | ||||||||
Feature
1. compact structure, light weight, low vibration and friction
2. high precision,
3. space and cost saving
4. best quality, long life
Application
Aerospace and defense
Astronomy instrumentation
Fixturing and workholding equipment
Food processing equipment
Glassworking equipment
Index and rotary tables
Packaging equipment
Machine tools
Medical systems and medical devices
Optical scanning equipment
Tire making equipment
bulk crb thin-section crossed roller bearings
More information ,pls contact us ~
