5 Ton Hydraulic Closed Die Forging Hammer Factory
- Qingdao Port, Shanghai Port, Tianjin Port
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 90 days
You May Like
-
Closed Die Drop Forging Hammer Steel Closed Die Drop Forging Hammer
-
Closed Die Drop Forging Hammer Connecting Rod Drop Forging Hammer
-
Spanner Wrench Closed Die Drop Forging Hammer Forging Spanner Wrench Drop Forging Hammer
-
Connecting Rod 16kj Closed Die Drop Forging Hammer for Sale
-
25kj Closed Die Drop Forging Hammer Manufacturer
-
9kg Pneumatic Forging Hammer for Sale
Product Details
| Brand Name | Anyang Forging Press | Place of Origin | China | |
| Certification | CE ISO | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | one year | Condition | New | |
| Power(W) | 55000 - 750000 |
Product Description
Fully hydraulic closed die forging hammer is driven by hydraulic oil without nitrogen gas, is mainly applied in many kinds of closed die forgings,such as automobile forgings,tractor forgings,agricultural equipment forgings, oil and gas industry die forgings, electrical power station die forgings and industrial forgings
Hydraulic closed die forging hammer Introduction
C86Y series hydraulic die forging hammer is fully hydraulic driven without gas. Fully hydraulic closed die forging hammer is used for closed / impression die forging.
Technical characteristics
Highly integrated fully hydraulic control system, low carbon, no leakage, more reliable.
Large flow hitting valve [patent design], sensitive response, high frequency.
Built-in secondary hydraulic cushion device[ patent design], realized flexible upper limit, no top hitting.
Tup return fast, die contact time is short and will return at once, die life is longer.
'X' type guide rail, it can do multi-cavity forging, high forging precision ,long hammer rod life.
Automatic emergency anti hammer rod breaking cover, anti oil leak protection and safety.
Multilevel security protection hydraulic device, system stability, high safety.
Lead control operate valve, reliable control, operating force is small, low labor intensity.
Traditional hand operated model, the original operator can operate the hammer easily.
Fully Hydraulic Closed Die Forging Hammer Parameter
| Item | Unit | C86Y-25 | C86Y-50 | C86Y-75 | C86Y-125 | C86Y-200 | C86Y-250 | C86Y-400 | C86Y-450 |
| (1T) | (2T) | (3T) | (5T) | (8T) | (10T) | (16T) | (18T) | ||
| Below energy | KJ | 25 | 50 | 75 | 125 | 200 | 250 | 400 | 450 |
Ram Weight | kg | 1000 | 2000 | 3000 | 5000 | 8000 | 10000 | 16000 | 18000 |
| Max. stroke | mm | 1000 | 1200 | 1250 | 1300 | 1350 | 1400 | 1500 | 1500 |
| Hit frequency | min-1 | 55-70 | 55-70 | 55-70 | 55-65 | 55-65 | 50-60 | 50-55 | 45-50 |
| Motor power | kw | 55×1 | 55×2 | 55×3 | 55×4 | 75×5 | 75×6 | 75×8 | 75×10 |
Min height of close die dovetail ) | mm | 220 | 260 | 350 | 400 | 430 | 450 | 500 | 500 |
Outside size (L×W×H) | mm | 2400× | 3000× | 3200× | 3700× | 4300× | 4400× | 4500× | 4500× |
| 1400× | 1700× | 1800× | 2100× | 2700× | 2700× | 2600× | 2800× | ||
| 7000 | 7500 | 8000 | 8200 | 8800 | 9000 | 9800 | 10000 |
