Gas dilution mixing system

GDS dynamic distribution system is a series of preciseness reliable performance of the gas dynamic dilution device, in line with the national standard, the optional configuration 2 ~ 12 mass flow controller, applied to online or laboratory preparation of standard gas, as well as to the air pocket, cylinders, such as syringe samples diluted, the system can not only the preparation of two component gases also can be mixed five-way (at most) can be extended to 12 road preparation of multicomponent mixture.In the process of dilution, the user can choose either single point dilution or multi-point continuous dilution with different concentrations. The dilution ratio can be directly set through the touch screen to quickly and conveniently complete the required sample preparation.

I. system name: five-component dynamic gas distribution system

Ii. System model: gds-d5

Three, use

The system can be used for the preparation of multi-component standard gas which is gaseous at room temperature and can be used for the research of multi-point calibration of sensors.

Product features

◆ the number of channels 2-12 channels are optional, supporting a variety of gas preparation

◆ the air path adopts anti-corrosion and anti-adsorption materials

◆ the speed response can ignore the preheating process

◆ meet laboratory and all on-line gas sample dilution

V. system composition

The system is mainly composed of the following parts:

Iv. The components of the system are as follows:

Five-component dynamic gas distribution system

The system USES the most advanced measurement and control technology in the world, the equipment is stable and reliable, and the preparation accuracy is high.Full automatic control, simple and reliable operation.The equipment is integrated in a case.The appearance is simple and beautiful.Main equipment includes: operating software, LCD touch screen, mass flow controller, one-way valve, globe valve, fire resistance valve, gas mixing pipeline, etc.

The system has 5 mass flow controllers and can achieve 2 ~ 5 component gas mixing ratio.Can set aside a few more, in order to facilitate the later expansion, there are as many as 50 or 60 kinds of gas in the system database, when using the computer directly access to the choice.Maximum flow rate of mixed gas: ≈ 5 L/min.Valve channel: 5 channels, expandable channels up to 12 channels.

See gas flow chart (attached form 1)

(attached form 1) the pictures are for reference only

List of major equipment

1. Gas mass flow controller (★ can use the original import)

Range e1:0.0 ~ 3000ml/min

Range e2:0.1 ~ 1000ml/min

Range e3:0.1 ~ 1000ml/min

Range e4:0.1 ~ 500ml/min

Range e5:0.1 ~ 200ml /min

★ accuracy: ± 1.0% F.S

★ seal: Viton(high temperature resistant fluoro rubber)

Response time: 1...2 seconds

Repeatability: <±0.2% Rd

Range ratio: 1:50 (numerical mode: 1:187.5)

Leakage rate: tested <2 x 10-9 mbar l/s He

Power supply: + 15...24 VDC @ 320 ma

Operating temperature: -10...70 ℃

Pressure sensitivity: 0.1% Rd/bar typical N2;0.01% Rd/bar typical H2

Temperature sensitivity: Zero: <0.05% Rd /℃;Span: <0.05% Rd / ℃

Output: 4...20 ma, and RS - 232

★ support wifi function and remote control

U support RS232

★ antimagnetic seismic

2. Gas path

The gas path of the whole system is made of 316 stainless steel pipe or ptfe which is anticorrosive and anti-adsorption

Tube with smooth inner surface.

3. Computer and system software

1) the valve distribution system is operated by computer. The computer needs to provide its own or other purchased valve distribution software.

2) five-component dynamic air distribution system software

The valve system can set cylinders and corresponding ports as required.And can pass through

Flow mode and concentration mode valve.Through software automatic calculation, the gas mass flow controller automatically adjusts and controls the gas flow to realize the gas ratio concentration requirement.
