Home > Products > Patch Antenna > 3G Patch Antenna With SMA Connector 3m Sticky Antenna
3G Patch Antenna With SMA Connector 3m Sticky Antenna
- Shenzhen
- T/T PayPal Other
- 5 days
You May Like
-
GSM Patch Antenna 3m Sticky Antenna With SMA Connector
-
WiFi Patch Antenna Internal PCB Antenna With Ipex Connector
-
2.4G WiFi Internal PCB Antenna With 3dBi Gain 2.4G Patch Antenna
-
698-4000MHz Lpda Antenna With 11dBi Gain 5g Logarithmic Periodic Antenna
-
GPS/Glonass Antenna With Fakra H Pink Connector
-
Gpsglonass Antenna With Green Pioneer Connector 28dBi Gain
Product Details
| Place of Origin | China | Model Number | GL-DY017 |
Product Description
Product Features
* Compact construction
* Beautiful shape
* Convenient installation
* Stable performance
Product Applications
* Car Anti-theft System
* Terminal data transmission
3G Patch Antenna | |
| GL-DY017 | |
Electrical Index | |
Frequency-MHz | 698-960/1710-2170 |
VSWR | <1.5 |
Nominal Impedance-Ω | 50 |
Polarization | Vertical |
Gain-dBi | 2.5 |
Mechanical Index | |
Cable Length | RG174, .2.5m |
Connector | SMA male or Fakra |
Antenna Dimension-mm | 115.6*21.7*5.8 |
Installation Way | 3M sticky |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours |
Environmentally Friendly | ROHS Compliant |
Temperature-oC | -40~+85 |
Humidity-% | 5~95 |
FAQ
Q: Can I get one sample?
A: Yes, sample is available.
Q: Have GNSS Antenna 100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working days for the sample, 10-15 working days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A:T/T, Paypal, western union etc.
Q:May I visit your company?
A: Sure, welcome any time.
Q: How long of the warranty?
A: one year for antennas and half a year for assembly cables and connectors
