High stability electro - optical intensity modulation module
- 1000 Piece / Pieces per Month
- tianjing
- T/T Credit Card
- 7 days
You May Like
-
1550nm Suppression Carrier Single Side-band Modulator
-
ROFea -ABC automatic bias point controller
-
ROF-AM-10 1550nm Electro-optic intensity modulator
-
ROF-AMBOX 10G Intensity Modulator
-
ROF-AM-HER high extinction ratio of light intensity modulator
-
ROF-AM-HER high extinction ratio of light intensity modulator
Product Details
| Brand Name | ROFea | Place of Origin | China | |
| Model Number | ROF-RF-10 |
Product Description
High stability electro - optical intensity modulation module
Product description |
ROF-AMBC series of high stability electro-optical intensity modulation module are my company's latest products, which integrates the electro-optical intensity modulator and the corresponding bias circuit and solve the problem of electro-optical intensity modulator modulation performance affected by the external environment, and ensuring that the electro-optical modulator can work stably at QUAN +/-, NULL or PEAK for a long term , and completed miniaturization and easy to system integrate system.
Features l Low insertion loss l High modulation bandwidth l Low half-wave voltage |
Classifications l Optional wavelength:1310nm、1550nm and so on l Modulation bandwidth ：10GHz、20GHz、40GHz |
Applications l High-speed optical fiber transmission equipment l Microwave photon link l Phase array Schematics
Performance parameters |
Parameter | Symbol | Min | Typ | Max | Unit | ||
Optical parameters | |||||||
Operating wavelength | l | 1525 | 1565 | nm | |||
Insertion loss | IL | 4 | 5 | dB | |||
Optical return loss | ORL | -45 | dB | ||||
Switch extinction ratio@DC | ER@DC | 25 | dB | ||||
Output optical power stability | 0.2 | dB | |||||
Optical fiber | input side | Panda PM Fujikura SM 15-P-8/125-UV/UV-400 | |||||
output side | Corning SMF-28 | ||||||
Optical interface | FC/PC、FC/APC or user specified | ||||||
Electrical parameters | |||||||
Operating bandwidth （-3dB） | S21 | 10 | 12 | GHz | |||
Half-wave voltage Vpi | RF | Vπ@50KHz | 5 | V | |||
Bias | Vπ@Bias | 6 | V | ||||
Electrical return loss | S11 | -12 | -10 | dB | |||
Input impedance | RF | ZRF | 50 | W | |||
Electrical interface | SMA(f) | ||||||
limit condition |
Parameter | Symbol | Unit | Min | Typ | Max | ||||
Output optical power | Pin,Max | dBm | 20 | ||||||
RF output power | dBm | 28 | |||||||
Operating voltage | Vb | V | +/-12 | ||||||
Operating temperature | Top | ℃ | -10 | 60 | |||||
Storage temperature | Tst | ℃ | -40 | 85 | |||||
Humidity | RH | % | 5 | 90 | |||||
Characteristic curve
|
S11&S21 curve
Ordering information |
ROF | AMBC | 15 | 10G | XX | XX |
Modulator type ： AMBC ---Intensity modulator integrated bias point control circuit | Operating Wavelength ： 15---1550nm | Operating bandwidth ： 10G---10GHz | Input output optical fiber ： PS ---PM/SMF | Connector ： FA ---FC/APC FP ---FC/PC SP---user specified |
*please contact our seller if you have special requirements
